Summary of Contents for absob AB-103
- Page 1 GET FREE 1 YEAR EXTENDED WARRANTY Scan the QR code or visit the link below https://absob.vip/ @absobglobal absob-cs@outlook.com...
-
Page 2: Product Introduction
Product introduction ① ④ ⑤ ② ③ ⑥ ⑦ ⑨ ⑩ ⑧ ① Dust bin ② HEPA filter ③ Dust bin lock ④ LED lights ⑤ Switch ⑦ handle ⑧ side air outlet ⑨ rear air outlet ⑥ Power Indicator ⑩... -
Page 3: Parts List
1.Long mouth tip*1 2.Brush tip*1 4.Hose fittings*2 5.Type-C charging cable*1 Product parameters Dust cup capacity: 0.35L Product weight: 730g Product Model: AB-103 Battery capacity: 2000mAh*2 Working voltage: DC 7.4V Product size: 353*111*106mm Rated power: 60W Vacuum degree: 10000Pa Operating noise：＜85dB... - Page 4 Precautions Please read this instruction manual carefully before using the product book and keep it in a safe place for future reference. Ready to use 1. Please fully charge this product before using it for the first time. 2. The power indicator flashes to indicate charging.
- Page 5 Notice 1. Please use an adapter or car charger with a rated voltage of 5V and a rated current of not less than 2A to charge this product. 2. Please be careful not to block the exhaust port when vacuuming. 3.
-
Page 6: How To Charge
How to charge? Use an adapter or car charger with a rated voltage of 5V and a rated current of not less than 2A. Insert 1.Connect the charging 2.USB connection car cable to the vacuum charger/power adapter cleaner device Insert 3. - Page 7 How to use the host? Push the power switch to the front Strong mode, suction 000Pa Turn the power switch to the rear power off push forward...
-
Page 8: How To Use Accessories
How to use accessories? 1. Suction nozzle: suitable for dust cleaning of various gaps such as doors, seats and ashtrays. 2. Brush: It combines the dual functions of suction and wiping, and is suitable for dust cleaning of various cushions, suede parts of foot pads, and air-conditioning outlets. - Page 9 How to clean up? Make sure the dust bin is emptied and cleaned regularly. Press the dust bin lock Take out the Hypa filter in and remove the dust the dust bin and put the bin from the body garbage into the trash can If necessary, clean the dust To re-install the dust bin, with a slightly damp cloth...
- Page 10 A: Check if the Hypa filter is installed Q: The product cannot be charged A: Check whether the charging cable is connected to the rated power Voltage 5V, rated current not less than 2A adaptation device or car charger for charging @absobglobal absob-cs@outlook.com...
