AQUAZILLA AQ-PL-05-100FT 5/8 Operating Instructions

Operating Instructions
Extending the hose
(Caution: ① Always hold the hose until it completely retract into the hose reel. ②The yellow
tape marks the end of the hose length)
1, Pull the hose out to the desired length. The hose will automatically lock in position.
Anywhere lock: Pull out the hose to the desired length and then stop pulling so the reel can lock
in the desired position.
2,To retract, pull out about 300mm of hose; the hose will retract back into the reel. If you pulling
over than 300mm, the hose will be locked in new length again. ONLY A short tug could unlock the
hose to let it retract all the way back smoothly and nicely.
Noted :
1, To retract, it is suggested that a minimum of 15" has been extended.
2, During retraction, always hold on to the hose and follow the retraction until it is finished.
Under no circumstances should you let go of the hose as it will retract at a high speed potentially
causing injury to any person standing nearby, and/or damaging to the hose and hose reel.
3, When the hose is twisted, it is necessary to extend the hose to its full length, untwist the hose
and then allow it to retract.
Adjusting the stop-ball
(Caution: Always make sure the hose reel is locked before removing the stop ball, and make sure
the stop-ball is securely fastened before unlocking the reel.)
The location of the stop ball can be adjusted to allow more or less hose exposed when fully
rewound.
1, Pull out the hose to the desired length, ensuring the hose reel is locked ( will not rewind).
2, Loose two screws in the stop ball and move it to the desired location.
3, And tight screws in the desired location.
4, Unlock the hose.
