Summary of Contents for Revotech Industries I706-POE
- Page 1 Revotech® copyright Simple Instruction , ,, Revotech® copyright...
- Page 2 Revotech® copyright 1. Overview An IP camera (hereinafter referred to as IPC) is a new product integrating network video technologies into a traditional camera. The IPC can realizesimpler monitoring (particularly remote monitoring), easier construction and maintenance, better audio and alarm linkage, more flexible record storage,more enriched product selection, much clearer video effect, and more perfect monitoring management.
- Page 3 Revotech® copyright 2. How to connect the camera with computer? 1. Connect the camera. Connect the camera with power supply and connect the camera to the Router with network cable. Note: (1). 12V/2A power adapter will be better. (2). If your camera support POE function, then you need to connect it with a 802.3af Standard POE Switch.
- Page 4 Revotech® copyright (2). Uncompress and install the software, please choose English language. 3. Connecting (1) When you open the software, it will auto search and connect with the devices in the LAN. (2) If it do not connect automatically, you need to connect yourself. Click any button and it need to login.
- Page 5 Revotech® copyright (3) Right click, and click “Devices”. Revotech® copyright...
- Page 6 Revotech® copyright (4) Click “Search More” and find your camera, double click it and then click "exit". (5) Right click the Device that you just add, and click "Connect Channel". Then you can get the image of your camera now. Revotech®...
- Page 7 Revotech® copyright 3. What is Device ID and how to get Device ID is a unique ID of our IP Camera, we can use it to connect with the CMS Software and smartphone. We can get it from the CMS software. Path: Remote configuration –...
- Page 8 Revotech® copyright (2) It will ask you to change the password, you can click “OK” to change the password or just click “Cancel”. Notice: The password of the camera must be numbers or letters, can not be the special character like “@#$%^”. And the length of the password can not longer than 12 digit.
- Page 9 Revotech® copyright (3) After you go into the menu of the camera, click “System”, and you can get the ID of the camera now. 4. How to download and use the Smartphone APP? IMPORTANT NOTE: Recently our P2P service is having problem sometimes, if you can not connect the camera via NVSEE Int’l (show offline), please contact with us (revotech_eu@hotmail.com) or contact with the retailer for help to make the device online.
- Page 10 Revotech® copyright Or you can scan this two-dimension code to download it. Revotech® copyright...
- Page 11 Revotech® copyright 2. Open the APP and Add a Device (1) Sign up and login in the app, and then click “+” to add a camera. (2) Make the camera and the smartphone in the same network, and click “Scan in LAN”, after the app find the camera, click “+”...
- Page 12 Revotech® copyright Or input the Device ID Manually and click “Confirm”. Input “1” for “CH Amount” and input the password, and then click “Add”. Revotech® copyright...
- Page 13 Revotech® copyright (3) And then click the camera you just add and you can check the image of your camera now. Notice: 1. One device can only bind to one app account, for other app account, need to use the first account share to other account. One device support 1 binding account and 10 sharing account.
- Page 14 Revotech® copyright (2) Then you can got a QR Code of the camera, share that QR code to other account, use the scan function of the NVSEE app then the account can add the camera. Revotech® copyright...
- Page 15 Revotech® copyright (3) Click the “Share Manager”, and you can edit the authority of the sharing account or delete the sharing account. 6. How to change the camera into static IP address. The camera is default dynamic IP address, if you need to change it into static IP address, please check here: Revotech®...
- Page 16 Revotech® copyright (1) Right click the camera and click “Remote configuration”. (2) Click “Network” – “Basic” – “TCP/IP”, cancel the “DHCP” and “IP Self Adaption”. And change the IP address into what you want, and then click “Save”. Then the IP address change into Static IP address now. Revotech®...
- Page 17 Revotech® copyright 7. How to connect the camera via the browser. (1) Get the IP address from the network setting via our CMS software and input it in the IE browser (IE10 or IE11), and login in the camera. (2) Install the “VLC media player”. (If it do not show the installation message, you can click “Download”...
- Page 18 Revotech® copyright (3) You can get the image and all setting of the camera now. 8. How to set the motion alarm function? 1. Set the email alarm. (1) Right click the camera and click “Remote configuration”. Revotech® copyright...
- Page 19 Revotech® copyright (2) Click “Network” – “Advanced”, and input the smtp parameter of your email and click “Test Email”. (3) After it show the “Succeeded” information, click “Save”. Revotech® copyright...
- Page 20 Revotech® copyright 2. Set the motion detection function. (1) Click “Alarm” and “Enable Human Detection”. (2) Click “Alarm Linkage” and click “Send Alarm Email”. The motion detection function is enable now, anything move from the camera, it will send you a email with a screenshot. Note: Q: I have set the function as the instruction, but I can’t receive the message? Revotech®...
- Page 21 Revotech® copyright A: Please check the camera logs (Path: Remote configuration– system - Logs), you can see if the camera have sent the email. And if it have sent, then the email may intercept by the system of Inbox, please check the setting of the Inbox.
- Page 22 Revotech® copyright (2) Click “Alarm” and “Enable Human Detection”. (3) Click “Alarm Linkage” and click “Send to Client”. Revotech® copyright...
- Page 23 Revotech® copyright 2. Set the motion record function. (1) Click “Setting” (2) Click “Alarm In”. * Click “Receive remote alarm signals” * Click “Ok”. Revotech® copyright...
- Page 24 Revotech® copyright (3) Click “Alarm Out”. * Input Alarm Lasting time (Record Lasting Time) * Click “Start Recording” * Click “Ok”. (4) The motion record function is successfully setup, and if anything move from the camera, it will trigger the alarm function and start record. Revotech®...
- Page 25 Revotech® copyright (5) You can set the File storage path in “Setting” – “Record Setting” and find the record file in your computer (Folder name: JdvrFile). Revotech® copyright...
-
Page 26: Other Information
Revotech® copyright 10. Other information PORT Information For 16EV2 camera version: HTTP Port: 80 Onvif Port: 80 RTSP Port: 8554 For FHW camera version: HTTP Port: 80 Onvif Port: 6688 RTSP Port: 8554 Notice: The HTTP port of FHW version can not be changed, please do not change it in the setting.
