Mophorn A-80S Manual

With smart appearance, reliable quality, Fusion Splicer is a special design for the installation, operation
and maintenance of optical fiber specially design a precision, durable, convenient optical fiber construction
instrument. Widely used in the construction, inspection, maintenance of fiber cable.
Features
● Used for FTTH and ordinary fiber project
● 8 sec splicing time and 30 sec heat time
● 300 X or Y view, 200 X and Y view
● 5 inch digital high-quality LCD screen, observe X and Y view at same time
● Three in one fixture, splicing single fiber, cable indoor and pigtail
● Built in large capacity lithium battery of 200 times splicing and heating
● Small size and light weight, 1.98KG including battery
●V type high power automatic heater with steel based thick film，high thermal efficiency, fast heating and long life
Specifications
Model
Splicing Type
Splicing Loss
Return Loss
Splicing Mode
Fiber Alignment
Applicable Fiber
Splicing Time
Heat Time
Cleaved Length
Fiber Image/ Magnification
View Display
Tension Test
Heat Shrinkable Sleeve
Battery Capacity
Battery Life
Electrodes Life
Power Source
Interface
Construction Lighting
Power supply
Operating Condition
Weight
Dimension (LxWxH)
High Precision Fusion Splicer
Core to core alignment by PAS technology
●
●With 5200 mAh Ultra-large capacity Li battery
●Large amplification and clear core
Fusion Splicer
SM, MM, DS, NZDS
0.02dB(SM)，0.01dB(MM)，0.04dB(DS)，0.04dB(NZDS)
>60dB
Manual, Half Auto, Auto
Core to Core Alignment by PAS technology
Cable indoor and 0.25mm,0.9mm fiber,
≤9s
≤30s Auto Heat
12～16mm
300/200
5 inch digital high-quality LCD screen
Standard 2N (option)
60mm, 40mm and serials heat Shrinkable Sleeve
200 cycles splicing and heating, 3 hours charging time
( splicing and charging at same time)
Cycling charge 300-500 times, easy to replace battery
3000, easy to replace electrodes
≤20W
USB Convenient data download and software update
Built in high brightness, wide range of lights, easy to operate at night
Built in lithium battery 5200mAh 11.1V; external adapter,
input: AC100-240V, output: DC13.5V/4.5A
0-5000m above sea level, Temperature: -10-60℃,
Humidity:
0～95%RH (No dew)
1.98 KG (including battery)
135mm(L)×158mm(W)×155mm(H)
SC connector(option)
