Summary of Contents for Allturn D1865
- Page 1 User's Manual of Plastic Welding Gun for Lithium Battery D1865 D2170 Straight handle type D1865-S D2170-S Bending type Please read the user manual carefully before use...
-
Page 2: Machine Specifications
Machine specifications Machine model D1865 /D1865-S Machine D2170 /D2170-S number model Rated voltage 3.7V rated 3.7V voltage 4.5V -5V Charging voltage charging 4.5V -5V voltage Charging joint Ttype -c Ttype -c Charging joint Value nail 200 PCS quantity Value nail... - Page 3 PRODUCT REPAIR AND MAINTENANCE To reduce harm, users Be careful should carefully read the instructions Before inspecting or maintaining the tool, be sure to turn off the tool power and remove the battery pack. Class II tools Do not use gasoline, benzene, diluents, alcohol, or similar items to clean tools.
-
Page 4: Safety Alert
SELECTION OF PLASTIC WELDING GUN AND WELDING NAIL Fracture plastic welding nail type selection THE MAIN USES OF PLASTIC WELDING GUNS SAFETY ALERT This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involvedChildren shall not play with the appliancecleaning and user maintenance shall not be made by children without supervisionlf... - Page 5 TECHNICAL PARAMETERS Voltage Capacity Charging time Output voltage Output current Weight 3.7V 2600/4500mAh 4-6H 0-5V 0-65A 0.22kg SAFETY GUIDELINES Warning! Read all warnings and instructions. Failure to follow warnings and instructions can lead to electric shock fire or serious injury. The following warning term "electric tools"...
- Page 6 FUNCTION DESCRIPTION OF STRAIGHT HANDLE LITHIUM PLASTIC WELDING GUN Place the welding nail into the installation hole of the welding nail, align it After inserting the welding nail, lightly press the switch button to start with the plastic part that needs to be repaired, press the switch, and working.
- Page 7 FUNCTION DESCRIPTION OF FOLDABLE LITHIUM BATTERY PLASTIC WELDING GUN After inserting the welding nail, lightly press the switch button to start Place the welding nail into the installation hole of the welding nail, align it working. Pay attention to the long press and release of the switch to with the plastic part that needs to be repaired, press the switch, and stop working.
- Page 8 Function descript ion of straight handle lithium plastic welding gunFunction descript ion of straight handle lithium plastic welding gun...
