koller AQ51000 How To Set

HOW TO SET UP THE 5V POWER SUPPLY
Power Adapter
Power Connector
(USB micro-B Connector)
GETTING STARTED
Power adapter plugs into wall receptacle
and converts AC to a single DC voltage
required for the aquarium's LED light
1. Carefully remove the power adapter from the
packaging.
2. Unwrap the tie from the power cable and straighten
power cable.
3. Locate the connector port on the LED light, usually
found at the back of the light.
4. Grasp the power connector and insert into the
connector port on the LED light, Figure 1.
5. Form a Drip Loop beneath the electrical receptacle,
Figure 2. Creating a Drip Loop is a way to plug in the
power adapter into the electrical supply when it used
for equipment involving water. The Drip Loop ensures
that the power cable loops down below the electrical
receptacle before it is plugged into the receptacle,
allowing any water dripping down the cord to land on
the floor before reaching the electrical receptacle.
6. Insert the electrical plug into the electrical receptacle.
7. The LED light is now ready to be used.
Power Cable
Safety Notes:
LED Light
Connector Port

Only use this product for the intended purpose.

Do not store in extreme temperatures as damage
to the circuit board can occur.

Do not bend or crush power cable.

Do not attempt to service or repair the product
yourself.

Do not use the product if the power supply or
power cable becomes damaged.

Do not modify the product in any way. Doing so
voids the warranty.

Connect the product only to a Connector Port that
has been approved for the device.

The power adapter has marked voltage and current
ranges in strict accordance with the device's
parameter standards.
Product Specification:
Input: 100 – 240V – 50/60Hz .2A Max
Output: 5V 1000mA
Plug: US
Important: Indoor Use Only
Made in China
Drip Loop
ASZEC9S
Power Connector
