Single Way Relay Module Delay Power-off Trigger
Delay Cycle Timing Circuit Switch
Product Highlights:
1.LCD Display, can clearly and directly show the current mode and parameters.
2.Opt coupler isolation, strong anti-interference ability, and industrial grade
circuit board.
3.Support high & low level trigger, switching value control; apply for most of
occasions.
4.Wide input voltage range (6~30V), also supports micro USB 5.0V power
supply. It is convenient to use.
5.Support UART data upload and parameters setting.
6.Stop button to be provided emergency stop function, with reserve protection
which it will not be burned under the condition of reserving.
7.Sleep mode: Without any operation within 5 minutes will close automatically
the LCD backlight. Any button can wake up.
8.OP/CL/LOP parameters can be modified and saved, and they are individual.
9.All setting parameters are automatically saved by power-fail.
Product Parameters:
Working voltage: 6V~30V, support micro USB 5.0 V power supply
Working current: 50mA.
Static Current: 15mA
Max. Output load: DC 30V 5A and AC 220V 5A.
Trigger signal source: High level trigger (3.0V~24.0V), low level trigger (0.0V ~
0.2V), switching value control (potential free contact)
Service life: more than 100,000 times
Working temperature: -40-85°C
OP
operation time
CL
close time,
LOP
loop times (1 - 9999 times, "
Module Introduction :
Timing state and time
Current working mode
High level trigger +
Signal GND
Low level trigger -
+
Power
6.0V~30V
-
supply
STOP
Wiring Diagram :
MicroUSB 5.0V power supply
High level trigger +
Signal GND
Low level trigger -
+
Power
6.0V~30V
-
supply
Weak current control strong current wiring diagram
High level trigger +
Signal GND
Low level trigger -
+
Power
6.0V~30V
-
supply
Wiring diagram for sharing one power supply
----
" represents infinite cycle)
MicroUSB 5.0V power supply
NC
COM
NO
Increase
Relay closing indicator
SET
Reduce
220VAC
Live line Null
+
Load
Load
Parameter Settings:
a) Long press SET to enter the setting interface;
b) Set the working mode, work mode flashes remind, set the working mode
by pressing UP / DOWN;
c) Short press SET to select the working mode and enter the system parameter
settings.
d) In the system parameter setting interface, short press SET to switch the
system parameters to be modified, and short press / long press UP/DOWN
to modify. (Note: Short press SET in P-1~P-3, P-7 modes is invalid)
e) In the
OP CL
the timer unit (1s/0.1s/0.01s/1min);
f) After all parameters are completed, long press SET to save the parameter
settings and exit the setting interface.
Working Modes Introduction(P1~P7):
P1: After the signal is triggered, the relay leads in
In the
OP
P2: After the signal is triggered, the relay leads in
In the
OP
P3: After the signal is triggered, the relay leads in
In the
OP
the signal is triggered again.
P4: After triggering signal and the relay is disconnected from
relay leads in
P5: After triggering signal and the relay is connected with
disconnects from
signal again, disconnects the relay, stops timing; and the times of cycles
(
LOP
) can be set.
P6: No need to triggered the signal after power on, the relay leads in
and disconnects
of cycles (
P7: Signal hold function: the relay maintains conduction if the signal is triggered,
or the timing is cleared. When the signal disappears and over
the relay disconnects. During the timing, there is another signal and the
timing is cleared.
How to choose the timing range:
0.01sec(min.)~9999 min(max.) can be adjusted continuously.
In the OP/CL parameter modification interface, press STOP shortly to select
the timing range;
XXXX
No decimal, timing range: 1sec~9999sec
XXX.X
The decimal point is in the ten, timing range:0.1sec~999.9sec
XX.XX
The decimal point is in the hundred, timing range:0.01sec~99.99sec
X.X.X.X
The decimal points light up,timing range:1min~9999min
For example, if you want to set the
point to ten digits. LCD displays "003.2".
Remote data upload and parameter setting functions:
The system supports UART parameter reading and writing functions;
UART:9600,8,1
line
-
Additional Functions:
a) Automatically hibernation function/ Low power function: In the running
interface, long press STOP to open or close automatically sleep function.
(L-P selects ON to start the hibernation function, and OFF turns off the
hibernation function);
b) Relay function selection: In the operation interface, shortly press STOP,
the relay function is started or closed, 'ON' meets the conduction condition
and the relay normally turns on, 'OFF' meets the conduction condition and
the relay does not turn on; In the 'OFF' state, the system flashes 'OUT'.
c) Parameters view: In the operation interface, short press SET to display
the current parameter setting in the system, without affecting the system
normal operation.
d) Display content switching: In P-5 P-6 mode, switch display content (run
time/cycle times) by pressing DOWN.
/
parameter modification interface, short press STOP to switch
time, it is invalid when the signal is triggered again.
time, it will re-timing when the signal is triggered again.
time, it is resetting, relay disconnected and stop timing when
OP
time. After timing is completed, disconnects the relay.
CL
time. And then recycles the above actions, get the
CL
time, and then loops the above actions; the number
LOP
) can be set.
OP
to 3.2 seconds, move the decimal
CMD
Read system parameters
read
OP: xxxx
OP: xxx.x
OP: xx.xx
OP: x.x.x.x
CL: xxxx
CL: xxx.x
CL: xx.xx
CL: x.x.x.x
LP: xxxx
on
off
Set the working mode(P1~P7)
PX
SKU:200350
OP
time and then disconnects;
OP
time and then disconnects;
OP
time and then disconnects;
CL
time, the
OP
time, the relay
OP
time
OP
time,
Function
1s
0.1s
0.01s
1 min
1s
0.1s
0.01s
1 min
Cycle times
Relay enable
Relay disable
