- Page 1 User Manual C-Play AV Receiver...
-
Page 2: Table Of Contents
CONTENTS Thank you for purchasing the C-Play AV Receiver Please read through these instructions so you will know how to operate your system properly. After you have finished reading the instructions, keep this document in a safe place for future reference. -------------- 1 ------------------------------------ 11 YOUR CP AV HEADUNIT... -
Page 3: Your Cp Av Headunit
For the best performance, we recom- mend that you have your Dasaita product installed by an authorized Dasaita dealer. If you would like to install this product on your own, we recommend for you to go through this manual to familiarize yourself with all the installation requirements and procedures. -
Page 4: Specification
SPECIFICATION General LCD Screen Size:6.2"7"8" 9" 10" CPU: SPHE8368-U,ARM Cortex-A9 Resolution: 1024x600/1280*720 DDR3: 256MB SPI-NAND:256MB OS: Linux Video External Video Input System: Operation Voltage: 8.5-16V NTSC/P AL/S ECAM Operation Temperature: -10°C - +70°C Video Input: 1 Storage Temperature: -20°C - +80°C Video Ouput: 2 Radio Tuner chipset: TDA7786 support RDS... -
Page 5: Wiring Diagram
USB 2 MIC input USB 1 BARKE CAM POWER AUX-V in Rear CAM In FCAM IN Video out 2 L Audio Input Video out 1 R Audio Input Front Right Speaker Rear Right Speaker Front Left Speaker Rear Left Speaker SUB-Out... -
Page 6: Front Panel
FRONT PANEL FUNCTION OPERATIONS & CONTROLS Short press to mute/cancel mute. 1. Power Long press to enter/quit standby mode. 2. Home Press to enter main menu. 3. Back Return to previous Mode 4. Volume Short press to increase volume. 5. Volume Short press to decrease volume. -
Page 7: Functions Application
FUNCTIONS APPLICATION Main menu (Please refer to the actual menu display for reference. ) C-Play : Shows Carplay or Android Auto based on your connected device Radio : Shows the Radio interface. Phone : Shows the Phone connection interface. BTMusic : Shows the BTmusic playback interface. USB : Shows Music playback interface AV in : Shows Audio and Video in interface Setting : Shows the Settings interface. -
Page 8: Radio
FUNCTIONS APPLICATION Radio Touch "Radio" in main menu to enter radio interface. 1 MAIN MENU : To return to the main menu 2 BACK : To back previous menu 3 FM : Switch between FM1/FM2/FM3 4 AM : Switch between AM1/AM2 5 RDS : a communications-protocol standard used with commercial FM Scans for available stations, long press to automatically search... -
Page 9: Phone
FUNCTIONS APPLICATION Phone This unit allows for hands free calling, using your phone's Blue- tooth connection to the unit, you'll be able to dial, answer, access phone book and playback music. 1 Keyboard: Dial 2 History: Calls record 3 Contacts: Phone book 4 Setup 5 Touch it to make a call. -
Page 10: Bt Music
FUNCTIONS APPLICATION BT Music Touch to enter BTmusic interface. EQ is the same assound settings EQ menu.(Lossless files playback FLAC/ WAV/ APE file formats. 1 Play/pause current song/media 2 Play previous song/media 3 Please next song/media Insert video input connector to input video's input jack, audio input conenc- to to input audio's input jack, touch "AUX"... -
Page 11: External Play Device
FUNCTIONS APPLICATION External Play Device When you connect a compatible data device to your unit, the fol- lowing interface will appear. 1 USB List Menu 2 Play previous song 3 Play/pause current song 4 Please next song Repeat mode: Repeat all - Repeat off - Repeat single 6 EQ settings Video 1 USB List Menu... -
Page 12: Android Auto
FUNCTIONS APPLICATION Android Auto Connect Phone to the unit to enter the Android Auto interface. The unit can be used to call, play music, view maps, check traffic information, watch videos, return to the unit's main interface, listen to Podcasts, read Au- diobooks and so on. - Page 13 FUNCTIONS APPLICATION EQ : Touch EQ icon to enter below menu: 1 Enter sound focus control function. 2 Enter equalized DIY setting 3 Fast set sound focus's control point. 4 Reset to default settings. 5 Slide left or right to switch EQ mode: rock/classical/jazz/etc.
-
Page 14: Settings
SETTINGS General Setting Touch to set relevant functions on/off. More items can be accessed by sliding the menu. Touch [ Language ] icon to Touch [ time ] to enter Language: Time Setting: enter language setting interface, select the time setting up/ down sliding can set year/ required language. -
Page 15: Smart Phone
SETTINGS Smart phone: Touch [ EQ ] Enter equalized setting Touch [ Smart phone ] Select default function for connected phones Bluetooth: Radio: Touch [ Bluetooth ] Touch [ Radio ] Select radio settings for Bluetooth area and default radio chip Touch [ Learning ] icon to Display : Touch [ Display ] Set Bright-... -
Page 16: Advanced
SETTINGS Left and right slide icon Touch [ Advanced ] set Dimmer : Advanced: to adjust screen's brightness.Touch [ necessary functions LED ] to set Stereo buttons illuminations Touch [ Parkline ] set Parkline: Touch [ Themes ]to select Themes: reverse parking lines and set mirror background photo reverse image... -
Page 17: Common Trouble-Shooting
COMMON TROUBLE-SHOOTING Problem Cause Correct action Check fuse Change fuse same as the old one Can not power on Some factors cause Press RES button on the panel by MPU wrong operation penpoint, then, power on After ignition Change battery switch off, setting Reset information and save or fuse...
