ATUMTEK ATSS052 User Manual

User Manual
1.3m Selfie Stick Tripod with
Bluetooth Remote
PRODUCT LINE GRAPH
Top cap
Bluetooth Remote
Power & Camera
2 in 1 Button
Tripod
Tripod Button
How to take out / put in wireless Bluetooth remote
Micro USB
charging port
1 Take out from the
Remote bottom.
How to use
Step 1: First pull out the phone holder, then press the tripod
button on bottom to unlock the 3 legs slightly.
ATTENTION:
When you press the bottom button, please avoid to hold the
top of tripod.
Step3: Put the tripod on flat surface, then adjust the extendable
stick arm for suitable height. If you do not need to use as tripod,
just pull out the stick arm out and adjust height to use it.
360° horizontally rotation of phone holder;
180° vertically rotation of adjustable bracket.
Step 2: Hold the bottom part of stick, then pull back the extend-
able stick one by one; finally push the phone holder back.
Note: If you open the tripod, the tripod will close automatically
when push back the aluminum alloy telescopic arm. Manual
operation is prohibited.
WARNING:
Do not push the 3 legs to close!!! It will break legs!!!
NOTE:
1. Open your built-in camera in your phone and press the power
& camera 2 in 1 button of once for taking a photo.
2. The wireless Bluetooth remote will connect directly after switch
on if it is already connected with the phone Bluetooth in last time.
3. The Bluetooth will automatically disconnect when the distance
is greater than or equal to 10 meters.
4. Turn the Bluetooth off in your phone and the wireless
Bluetooth remote will standby.
5. How to disconnect with your phone: Go to your phone
Bluetooth setting and disconnect "ATUMTEK" in paired devices.
6. Unavailable to use to control the built-in camera app in your
phone when the wireless Bluetooth remote in charging.
FCC Statement
Changes or modifications not expressly approved by the party responsible for compliance could void the
user's authority to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses, and can radiate radio
frequency energy, and if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
If you find our product satisfactory, please encourage us by sharing
If you need help with this purchase, please do not hesitate to contact us.
Phone Holder
Adjustable Bracket
Extendable Selfie
Stick Arm
1
2 Put in from the top
of the Remote.
2
360°
90°
90°
3
4
Contact us via Facebook Messenger (Recommended):
m.me/atumtekproducts
OR
www.atumtek.com
OR
support@atumtek.com
your user experience online.
Prolinx GmbH
REP
EC
Brehmstr.56, 40239 Duesseldorf Germany
Syncwire UK Ltd
REP
UK
C/O Lai and Co.109 Portland Street, Manchester, M1 6N
Product Parameters
Weight
Remote distance
Ambient temperature
Remote battery capacity
Input
Compatible devices
Device width
Extended length w/o
tripod activated
Extended length with
tripod activated
Folded size
Remote button lifespan
Step 2: Now pull the whole stick arm out, and the tripod will
open automatically.
ATTENTION:
1. Please fully pull out the stick arm so that the tripod can be
fully opened. Otherwise, tripod is not fully opened and will not
be stable.
Step 4: Widthwise set your phone inside the smartphone
holder by releasing the top cap.
Note: please avoid stuck the button of your phone.
How to Close
Step 1: Remove your mobile phone by releasing the top cap.
Bluetooth Connect Instruction
No. Status
Switch On
1
Long press camera button for 2 seconds, to open remote.
Switch Off
2
Long press camera button for 3 seconds, remote light is OFF.
Standby
Remote will standby after 10 minutes without operation;
3
Press the button for once to active, then green light will flash,
please reconnect with phone again.
4 Low Power
5 Charging
6 Fully Charged
7 Connected
8 Connectionless
*6 It takes about 2 hours to fully charge the remote.
First long press the camera button for 2 seconds, then connect
with "ATUMTEK" when green light is flashing, finally press once to
take a picture or record video.
If phone could not connect, clean phone Bluetooth connection
first, then try again; some Android phones use volume button to
control camera, so if you still could not use remote, please
choose "take a picture" or "take a video" on camera setting part.
Or please contact with seller directly to get support.
Approx. 330g
<10m(33ft)
-10℃~50 ℃
50 mAh
5V/110 mAh
IOS 7.0 and later/
Android 5.0 and later
Approx. 2.36" - 3.74"
Approx. 12.40" - 54.15"
Approx. 12.21" - 53.54"
Approx. 12.01" * Φ1.57"
>15,000 times
LED Light Indicator
Green Light Flashing
LED Light OFF
LED Light OFF
Red Light Flashing
Red Light ON
LED Light OFF
Green Light ON
Green Light Flashing
