TP-Link kasa smart KP200 Manual

Let's get started with your new Smart Outlet.
SAFETY FIRST SAFETY FIRST
Before installing, servicing or removing the outlet, read and follow all safety
precautions including the following:
• CAUTION – Risk of Electric Shock – More than one disconnect switch may be
required to de-energize the equipment before servicing. A circuit breaker which
disconnects the Line and Neutral conductor simultaneously is suitable. Ensure
power is off at the circuit breaker before removing or installing any outlet. Use a
non-contact voltage tester to ensure the power is off.
• The Smart Outlet must be installed and used in accordance with the National
Electric Code (NEC) or your local electrical code. If you are unfamiliar with these
codes and requirements, or are uncomfortable performing the installation, consult
a qualified electrician.
• Do not install the Smart Outlet with wet hands or when standing on wet or damp
surfaces.
• Install only in a suitable UL Listed outlet box (suitable dimensions: H > 2.95 in./75
mm, W >1.81 in./46 mm, D > 3.15 in./80 mm).
• Tighten terminal screws to 13 lbf-in.
STEP 1
Download & Install Kasa App
Get the Kasa Smart app from the
Apple App Store or Google Play.
STEP 2
Add Your Device
Tap the button in the Kasa app and
select Smart Plugs > Smart Outlet.
Follow Kasa app instructions to wire
your outlet and connect it to your
home network.
*Wiring instructions are also provided on the back page.
Kasa Smart Wi-Fi Outlet www.tp-link.com
