HYDE 079423091858 Instructions

9 Inch Round Dust-Free Sander,
Brush Ring Removal Instructions
Part #09185. During use with lower powered Wet/Dry Vacuums the brush ring can cause the user to press hard to create contact with the wall.
To alleviate this issue, you can remove the brush ring from the product. Wiping down of the surface after sanding to remove dust is recommended.
Step #1 Step #1
Remove the pole from the head
Step #5 Step #5
Use a screwdriver or other prying
tool to dislodge the brush ring
from the sanding head
Step #2 Step #2
Remove the foam pad from the inside of
the head by pulling apart hook and loop
Step #6 Step #6
Remove the brush ring and reattached
the foam pad to the sanding head
Step #3 Step #3
Vacuum any dust
inside the head
Step #7 Step #7
Reattach the Pole
Step #4 Step #4
Locate and remove the 4 small Phillips
screws securing the brush ring
Step #8 Step #8
Sander is now read to use
