1. Pull Lock/Release and fully open ratchet
2. Thread open end of belt completely through slot
Jameson products carry a warranty against any defect in material and workmanship for a period
of one year from date of shipment unless failure is due to misuse or improper application. Jameson
shall in no event be responsible or liable for modifications, alterations, misapplications or repairs
made to its products by purchaser or others. This warranty is limited to repair or replacement of the
product and does not include reimbursement for shipping or other expenses incurred. Jameson
disclaims any other express or implied warranty.
800.346.1956
Since 1956
Belt End
Slot
Spring Loaded
Lock/Release
4. Pull Lock/Release and move to partially closed position
5. Grasp handle and ratchet to tension
Warranty
WWW.JAMESONLLC.COM
BOOM MOUNT TOOL HOLDERS
INSTALLATION INSTRUCTIONS FOR NYLON WEB BELT
WITH RATCHET LOCK (24-09R)
Boom Tool Holders:
For Use On Round And Square Booms
3. Tuck end of belt back through slot
803.222.6400
24-02
24-03F
24-04
Belt End
Handle
BOM_MO3
