Summary of Contents for JMANCE U7

Page 1 2021-11...
Page 2 U7 User Manual...
Page 3 Preface We are very appreciated for you choosing and purchas- ing our car Entertainment system, to help you use this unit properly we sincerely suggest you read the manual carefully We will not inform you the speciﬁcation or design update thanks to the technology improvement. After you get this unit, please read all the information attached with it.
Page 4: Table Of Contents
Product overview Set-up Mount Power supply DC12V-24V Mount the U7 Precautions Home Screen Music interface video interface 09 Images interface carplay connect Android Auto connect Autolink connect Android Mirrorlink connect FM launch System settings Troubleshooting Environmental note Warranty regulations...
Page 5: Product Overview
PRODUCT OVERVIEW 1. Display 2. Audio 3. AV in 4. USB 5. TF Card 6. DC-12V Power Port 7. Microphone 8. On The Back 9. Mount 10. Konb 11. Lock 12. Adhesive Suction Cup 13. Power Plug...
Page 6 SET-UP MOUNT & POWER ON Step One Insert the adhesive suction cup mount into the bracket on the back of the and slide it up to lock it in place. Step Two Remove the protective ﬁlm from the adhesive suction cup on the bottom of the mount.
Page 7 Step Four Plug the adapter end of the power cable into your car's DC 12V -24V power outlet. U7 will automatically power on when your car is powered on, and will power oﬀ when your car is powered oﬀ.
Page 8: Mount The U7
Mount the U7 As seen in the ﬁ gure below, you can mount the U7 onto either the dashboard or windshield of your car. When mounting on the dashboard, you may ﬁ nd the surface of the dashboard is uneven. If so, use the supplied adhesive disk.
Page 9: Important Notes
Apps displayed on the U7(when pairing with either the Carplay or Android Auto app) will vary depending on the apps available on the connected phone. The U7 does not support it's own GPS. All Navigation app's are functionally dependent on the connected phone...
Page 10: Home Screen P06
HOME SCREEN 2 3 4 1. Main Menu 2. Day/Night Mode 3. Volume Controls 4. return 5. Carplay 6. Android Auto 7. Airplay 8. Phonelink 9. FM Radio 10. USB 11. SD Card 12. Music...
Page 11 MUSIC You can play audio ﬁles from a compatible USB drive or TF card. We recommend all songs be saved in either of the following formats (MP3/WMA/AAC/AC3/OGG/Real Audio/FLAG/APE) as other format types are not supported. Note: Featured information, including album cover and song name, may vary depending on the ﬁles hosted on the TF card or USB drive 1.
Page 12 Video You can play video ﬁles from a compatible USB drive or TF card We recommend all videos be saved in either of the following formats(AVI/RMVB/MPEG/RM/MK/MOV/MP4/ WMV/FLV)as other format typmat types are not supported. 1. Progress Bar 2. Previous Video 3.
Page 13 IMAGES You can view images from a compatible USB drive or TF card. We recommend all images be saved in either of the following formats(JPEG/JPG/PNG) as other format types are not supported. 90° 1. Previous image 2. Play Slideshow 3. Next image 4.
Page 14 Before using Carplay, please refer to the following ﬁgure to set up Carplay. Please use your iPhone for Bluetooth pairing. The Bluetooth search name is "Car****" or "U7" for pairing. Follow the iPhone's instructions to connect. Tip: After the CarPlay wireless connection is successful, the Bluetooth connection will be automatically disconnected, without clicking the Bluetooth connection, it will automatically switch to WiFi for data transmission.Carplay wired connection...
Page 15 Android Auto. Please use your Android phone for Bluetooth pairing. The Bluetooth search name is "Car****" or "U7" for pairing. Follow the instructions on the phone to connect. Tip: After the Android Auto wireless connection is successful, the Bluetooth connection will be automatically disconnected.
Page 16: How To Use Airplay
How to use AirPlay The screen mirroring function of this product supports wireless connection and wired connection. Before using screen mirroring, please refer to the following ﬁgure to set up iOSMirror. iPhone screen mirroring wireless link, before using this function, please make sure that the iPhone has established a WiFi connection with the product, the password is "88888888", in the iPhone screen mirroring, select "****-Airplay"...
Page 17 How to use Android phone mirror link. The product supports Android wireless connection and wired connection Before using screen mirroring, please refer to the following ﬁgure to set up AutoLink. Android phone wireless connection only supports 5G WiFi, 2.4G only supports wired data line connection.
Page 18: Fm Launch P14
FM launch This unit has built-in speakers, but if you want louder sound, you can transmit it to your car’s speakers: 1. Via FM radio transmitter-set the same FM radio channel on this unit and your car’s radio (Please avoid using channels occupied by FM radio stations) Via AUX cable-plug the auxiliary port into the original port of the car.
Page 19 Bluetooth, it searches for the U7 connection, and the mobile phone prompts the password 0000 or 1234 for pairing. When the mobile phone cannot search for the U7 Bluetooth, you can ﬁnd the mobile phone to ﬁnd the pairing connection in the U7 settings.
Page 20: Troubleshooting
① It is normal for the machine to work normally and the back is heated. There is a heat sink in the U7 to dissipate the heat of the IC. The built-in chip temperature is 50°C-75°C Machine heat, and the U7 can work normally.
Page 21: Environmental Note P17
Environmental note Name and content of hazardous substances in products Hexavalent Polybrominated Olfactory cadmium Lead biphenyls diphenyl ether chromium Part Name Motherboard Display screen plastic Metal Non-metal Data line antenna Appendix :Indicates that the content of the hazardous substance in all homogeneous materials of the part is below the limit requirement speciﬁed in the GB 4943.1-2011 standard X: Indicates that the content of the toxic substance in at least one of the homogeneous materials of the part exceeds the limit requirement speciﬁed in the GB 4943.1-2011 standard...
Page 22: Warranty Regulations P18
Warranty regulations 1. The free warranty period of this product is within twelve months from the purchase period. The purchase date is based on the product invoice or receipt. 2. The free warranty scope covers product failures caused by product quality problems 3.
Page 23: Warranty Card P19
Warranty Card user name Contact person User address contact number product name Product number Purchase date Serial number The cause of the failure and its date handling Maintenance records...
Page 24: Product Parameter P20
Product parameter name Light screen, car portable mobile phone interconnection screen Master Bundling and car regulationsSOC Conﬁguration Bundling and car regulationsSOC Limited wireless carplay, wired and wireless Apple Android Wireless system screen projection, U disk multimedia audio and video Screen 7 inch IPS material, 1024*600 resolution 64G, USB Storage expansion...
