Quick Start Guide
AM-1280800Q7TZQW-T07H
CONTENTS
page 2
Part 1: Connecting the driver card to the display
page 2
Part 2: Connecting the touch panel
© IGS Version V1
page 3
page 6
1 of 7
Advertisement
Summary of Contents for IDS AM-1280800Q7TZQW-T07H
- Page 1 © IGS Version V1 Quick Start Guide AM-1280800Q7TZQW-T07H CONTENTS Kit Content page 2 Part 1: Connecting the driver card to the display page 3 Required Parts not Supplied in Kit page 2 Part 2: Connecting the touch panel page 6 +44 (0)1635 294600 | info@i-lcd.com | www.i-lcd.com...
-
Page 2: Kit Contents
KIT CONTENTS Item Description Display with touch panel Driver card with Backlight PCB and control pad USB adapter cable from IDS Ltd REQUIRED PARTS NOT SUPPLIED IN THE KIT Item Description RS Part Number 12V 2A Power supply with 2.1mm x 5.5mm DC Jack... - Page 3 © IGS Version V1 PART 1: CONNECTING THE DRIVER CARD TO THE DISPLAY Connect the LVDS connector from the driver card to the back of the LCD. Take care to line up the pins and use the correct orientation as per the picture below The connection should look like this when the connector is fitted correctly Connect the backlight connector.
- Page 4 © IGS Version V1 CONNECT THE DRIVER CARD TO A POWER SUPPLY AND HDMI SOURCE The display has a connector with the USB Connections Turn the power switch to the ON position +44 (0)1635 294600 | info@i-lcd.com | www.i-lcd.com Intelligent Display Solutions, Unit 2, Berkshire Business Centre, Berkshire Drive, Thatcham, Berkshire, RG19 4EW 4 of 7 A division of Intelligent Group Solutions Ltd...
- Page 5 © IGS Version V1 CONNECT THE DRIVER CARD TO A POWER SUPPLY AND HDMI SOURCE +44 (0)1635 294600 | info@i-lcd.com | www.i-lcd.com Intelligent Display Solutions, Unit 2, Berkshire Business Centre, Berkshire Drive, Thatcham, Berkshire, RG19 4EW 5 of 7 A division of Intelligent Group Solutions Ltd...
- Page 6 © IGS Version V1 PART 2: CONNECTING THE TOUCH PANEL The display has PCB connector with the USB Connections Note the correct orientation and then push the USB adapter cable connector into the display touch connector Insert the USB connector into your PC The touch screen will be automatically recognised and installed by Windows 10.
-
Page 7: Further Information
The values contained in this data sheet can change due to technical innovation. Any such changes will be made without separate notification. If you require further assistance or have a specific or custom enquiry, please contact the IDS team via email or phone. Alternatively please visit our website for more product info and to see our full range.
