Summary of Contents for Hikity E30
- Page 1 E30 10.26-inch Android Player Product Manual...
- Page 2 Contents ··························································································- 2 - ·············································································· - 3 - ······················································································- 4 - ·················································································· - 5 - ·······················································································- 5 - ······················································································ - 6 - ··················································································- 7 - ······························································································· - 8 - A. Apple CarPlay ································································································- 9 - B. Android Auto ···································································································- 10 - C.
- Page 3 The E30 Android Player captures images of the surroundings of the vehicle via a wide-angle camera mounted outside the car and transmits them in real time to a smart screen. With the help of the system, drivers can visually see obstacles and pedestrians around vehicles, effectively reducing the occurrence of scratches, collisions, collapses and other accidents.
- Page 4 Name Graphic Instructions Number 10.26-inch HD display (1600*600) / touch / The host Bluetooth / WIFI / audio output / 1080P HD video / Type C interface power supply Type C power cord/ 7V~32V / 4A current / The power cord integrated cable / cigar lighter to take power Pull back camera AHD FHD (1080P)/4PIN BMW head...
-
Page 5: Function Introduction
Function Project Performance indicators introduction Simplified Chinese/English/Russian/Spanish/French/German/Japanese Language /Korean/Italian/Portuguese/Turkish/Vietnamese/Slovene/Polish/Icel andic/Malay/Indonesian/Filipino etc. System Interface Graphical menu operation Mode of Touch operation Real-time display 10.26-inch high-definition IPS screen, 1600*600 Video display The screen saver Can be set to 1 minute/5 minutes/30 minutes/long bright/screen off Reverse Reverse display Automatically switches to the rear view... - Page 6 The SD card can be used to store movies and music, which can be played after being inserted into the machine. Please choose a big brand SD card such as SanDisk, Kingston, Toshiba, Samsung. The speed certification must be able to reach at least Class10. Port Instructions Type-C interface...
- Page 7 Locate the drilling hole, find the appropriate installation position in the license plate attachment, mark it with a pen and then drill the appropriate size of the screw hole. Fix the camera to the rear of the car with screws, the reversing trigger wire (red thin wire) needs to be connected to the positive pole of the reversing light, and finally use the camera extension cable to connect to the monitor.
- Page 8 1 Recent: List all Manage running or open applications 2 Camera：View camera picture 3 Home page : Return to main page 4 Setting: Press and hold to enter the setting screen 5 Back: The previous screen is displayed 6 Navigation: Click to go to Google Maps 7 Bluetooth: Click to enter the operation interface of Bluetooth phone, Bluetooth music, etc 8 Mirror Link: Used for screen projection of iPhone or Android phone 9 CarPlay：Only used to connect to Apple CarPlay...
- Page 9 Find the CarPlay [ ] button on the home page, click to enter the interface above, click ] to select [ ], turn on the Bluetooth of the mobile phone, search the Bluetooth of the device and connect（PIN code: 0000）. Once the Bluetooth connection is successful, Apple CarPlay can be connected.
- Page 10 Find the Android Auto [ ] button on the home page, click to enter the interface above, click [ ] to select [ ], turn on the Bluetooth of the mobile phone, search the Bluetooth of the device and connect（PIN code: 0000）. Once the Bluetooth connection is successful, Android Auto can be connected.
- Page 11 Find the Bluetooth [ ] button on the home page, and then turn on the Bluetooth of the mobile phone. Connect the Bluetooth of the device. After the connection is successful, You can view your contacts, use your Bluetooth phone, play Bluetooth music, and check Bluetooth messages.
- Page 12 Insert USB flash drive, click [ to enter the USB flash drive screen, in which you can play videos, music, and pictures. Video: Support MP4, MOV, 3GP, MKV, FLV, WMV, not 2K and 4K resolution video, VOB, RMVB, Music: Support MP3, ogg, aac, flac, wav does not support WMA, ape Image: JPG, PNG, and BMP are supported - 11 -...
- Page 13 Once connected to the reversing camera, it will automatically jump to the camera screen when you reverse, with a reversing auxiliary cable. When driving normally, you can click Stream Media ] to view the situation behind the car. - 12 -...
- Page 14 Click FM [ ] to enter FM emission Settings. An FM transmitter is a device that converts audio signals into FM radio waves, which allows you to use any device with audio output in your car, such as cell phones, tablets, MP3s, USB sticks, etc. Just adjust the FM frequency of the device to match the frequency of the car radio.
- Page 15 Click Mirror Link [ ] to enter the wireless connection interface, and select Apple AirPlay ] for iPhone. Turn on the wireless hotspot of the device, and the mobile phone connects to the device hotspot. Open "Control Center" on your phone and tap "Screen Mirroring."...
-
Page 16: Specification
As shown in the figure, press and hold [ ] button on the home page to enter the setting interface. Icon Specification Set WiFi, flight mode, hotspot, VPN and other functions View application details and set permissions on the device Check the memory usage on the device View related Google services and Settings You can set the system language, time, and restore default Settings... - Page 17 Item Problem Solution Unable to start ① Check whether the DC head of the (Player supports cigarette lighter power cord is 7V-32V car use, damaged or aging. high voltage ② Check whether the fuse of the cannot be used) power plug is disconnected or burned. ①...
- Page 18 ③ Check if the camera format matches. ① Avoid direct sunlight or exposure to sunlight during use. The normal operating temperature of player is -4 The system is stuck ~ 149 ℉. ② or player After disconnecting the power overheating supply, the temperature of player will be lower than 149 ℉...
- Page 19 ① Only Android phones are supported. ② Update Auto and related applications on mobile phones to the latest version. ③ Android Auto Do not enable VPN on the mobile connection failed phone. ④ Check that the WiFi and Bluetooth functions of the mobile phone are normal.
- Page 20 Name E30 10.26-inch Android Player Chip High-performance SOC Wireless system Apple CarPlay, Android Auto Screen 10.26 inch IPS material,1600*600 resolution Storage expansion 64G≤Class10 TF Card ≤ 128G Wireless module Wi-Fi, BT, FM Launch module Camera Front camera and rear camera FM launch Adjustable frequency 87.5MHz-108MHz...
