Instruction and User Manual
Product ID: WTGD-110-020W
LED FLOODLIGHT WITH PIR SENSOR
Technical Data:
Power Requirement
Lighting Load
Detection Range
Detection Distance
Swiveling Angle
Mounting Height
Time Adjustment
Lux Adjustment
Working Temperature
Working Humidity
Floodlight Protection Rating
PIR Protection Rating
INTRODUCTION & WARRANTY:
Thank you for selecting and buying MIWAT product. MIWAT will serve you
the best. Please read these instructions carefully before starting the installation
and keep this manual handy for future reference. If you have any another query,
please contact our. The warranty is valid for 2 years from the date of purchase.
The warranty does not apply to damage caused by incorrect installation or
abnormal wear and tear. The company gives no warranty against damage to any
surface due to incorrect removal and installation of the product. The products
are suitable for 10-12 Hours Daily operation. Usage of product for 24 Hours a
day would void the warranty. This product is warranted for manufacturing
defects only.
MIWAT After Sales Service:
Please contact us on Amazon
110V
20W
120°
2-8 M (6~26 FT, <24° C)
Lamp Part: Vertical 90° ;Sensor Part: Horizontal 50° ,Vertical 40°
Recommended 1.8 ~ 2.5M (5.9 ~ 8.2 FT) Wall Mount
3 sec ~ 7 min
Approx. 0 ~ 1,000 Lux.
-20° C ~ +40° C
<93% RH
IP65
IP44
Advertisement
Summary of Contents for MIWAT WTGD-110-020W
- Page 1 IP44 INTRODUCTION & WARRANTY: Thank you for selecting and buying MIWAT product. MIWAT will serve you the best. Please read these instructions carefully before starting the installation and keep this manual handy for future reference. If you have any another query, please contact our.
-
Page 2: Installation Instruction
*Switch on the power and test if the light is working properly. *Remove the screw which is for mounting the bracket for the fixture. Remove the bracket. *Mark the hole position for fixing bracket onto the wall. Drill onto the wall at MIWAT After Sales Service: Please contact us on Amazon... - Page 3 Induction signals after the first induction, it will compute time once more on the basis of the first time-delay rest. Time-Delay is adjustable. It can be set according to the consumer’s desire. The minimum-time is 3s. The maximum is 7 min. MIWAT After Sales Service: Please contact us on Amazon...
- Page 4 Note: When testing in daylight, please turn the LUX knob to (SUN) position, otherwise the sensor lamp will not work. In front of the detection window please ensure there is no hinder or unrest objects effecting the detection. MIWAT After Sales Service: Please contact us on Amazon...
- Page 5 Amazon will connect you with them. You can also rate the seller or drop a comment about your shopping experience using a Leave seller feedback button. This option is available for up to 90 days after the date of your order. MIWAT After Sales Service: Please contact us on Amazon...
