Summary of Contents for Fierton 782910985775
- Page 1 High frequency suspension heat press transfer machine Please read the instructions carefully before use !
- Page 2 Parts Diagram ： Control Panel Handgrip High-frequency Power line energy converter Position plate Set hover bracket Pallet Figure 1 Machinery lift state Figure 2 Machinery Placement status...
- Page 3 2：Machinery Inner box fittings High temperature Screws and Main Engine( 1 pc) Pallet parts (4 pcs) Sponge( 1 pc) screwdrivers 3：The Assembly parts Figure 3 Form an angle Figure 4...
- Page 4 Figure 5 screwdrive Screws Figure 6...
- Page 5 Figure 8 Figure 7 ① As shown in figure 3, 4 ,5. select any two pieces, with the bottom facing up, buckle the hole and press hard in the direction of the arrow until it is fastened. ② As shown in figure 6, Tighten the screw with a screwdriver. ③...
- Page 6 ① Power on I. The device is 220 V 110V 1000W.Choose the right power supply first, insert the power line into □ □ the "power socket" and give the device electricity, as in Figure 10， Figure 11 power socket Pwer indication Figure 11 Figure 10 Room temperature...
- Page 7 Hold down the " " and " " keys simultaneously for 5 seconds until showing Figure 14. Figure 14 Press " " until showing Figure 15,16 . Press " " or " " key to switch to Fahrenheit "F" or Figure 15 Celsius "C"...
- Page 8 ③ TEMPERATURE SETTING Temperature Display Flash In the initial display state. press " " key / press " " or " " key to set the required temperature / To return to initial display state , press “ “ key again Figure 18 ④...
- Page 9 5：INSTRUCTIONS FOR THE POERATION OF HEAT TRANSFER ① Select a flat desktop and set the working environment with reference to the sixth point " THE SAFE USE INSTRUCION " ② Plug in the power supply, start up, set up the electronic control parameters, wait for heating.
- Page 10 ③ Choose the operating environment far away from flammable materials, and select wooden or energy-resistant material desktops for operating desktops. ④ It is strictly forbidden to place poor temperature resistance and flammable materials at the bottom of the placement plate. ⑤...
