Summary of Contents for Holyton HT50
- Page 1 Instructions For Use Gebrauchsanweisung V 2.0 HT50 holyton@foxmail.com (USA) holyton_eu@foxmail.com (EU) holyton_ca@foxmail.com (CA)
- Page 2 English 01-41 Deutsch 42-79...
-
Page 3: Table Of Contents
Contents Disclaimer & Warning ................... Safety Guidelines .................... Maintenance ....................Package Contents ..................Drone Details ....................Transmitter Details ..................Joystick Mode....................Preparation Before Flight Charging ..................... Download APP ..................Gimbal Cover .................... Drone Battery ................... Arm ......................TF Card ......................Propellers .................... - Page 4 Functions Details Emergency Stop ..................Speed Switch ....................Take Photo/Record Video................ Camera Angle Adjustment ..............Headless Mode .................... Return to Home (RTH) ................Stabilization Function Altitude-Hold Function ................Optical Flow Positioning ................APP Operation Instruction Operation Interface..................Beginner Mode..................... Specifications ....................Contact Us ......................
-
Page 5: Disclaimer & Warning
You agree to only use this product for it's designed purposes and in accordance with the local laws, regulations and all applicable policies and guidelines that Holyton may provide. 2. When using this product, please be sure to strictly abide by the specifica- tion requirements and safety guidelines stated in this document. -
Page 6: Flight Environment
SAFETY GUIDELINES ④ Please perform a thorough check of the product before each use. Inspect the integrity of the parts, any signs of cracks and wear off on the propellers, battery power and effectiveness of the indicator, etc. If there is any problem found after checking the drone, please refrain from using it until the problem is resolved. -
Page 7: Operation Requirements
SAFETY GUIDELINES OPERATION REQUIREMENTS ① DO NOT use this product to follow any moving vehicles. ② During the flight, turn off the motors only in an emergency. ③ When the battery runs low, return the drone back to your starting point. ④... - Page 8 SAFETY GUIDELINES ⑥ If the device is not going to be used for an extended period of time, please remove batteries to prevent potential damage to the drone from battery leakage. ⑦ Only use the USB charging cable that comes with the drone to charge the battery.
-
Page 9: Maintenance
MAINTENANCE ① Clean the drone after each use with a clean, soft cloth. ② Avoid prolonged exposure to direct sunlight and avoid buildup of heat on the drone or batteries. ③ This device is not waterproof and must not be submerged or subjected to water under any circumstance. -
Page 10: Package Contents
PACKAGE CONTENTS Drone Transmitter Drone Battery USB Charging Cable Screwdriver Propeller Instructions For Use Gebrauchsanweisung V 2.0 HT50 holyton@foxmail.com (USA) holyton_eu@foxmail.com (EU) holyton_ca@foxmail.com (CA) Instructions For Use -06-... -
Page 11: Drone Details
DRONE DETAILS Propeller B Propeller A Propeller A Propeller B HD Camera Drone Battery Drone Battery Indicator Lights -07-... -
Page 12: Transmitter Details
TRANSMITTER DETAILS Phone Holder Take Photo Lens Up Record Video Lens Down Right Joystick/ Left Joystick Speed Switch Folded Handle Power Switch Charging Port Unlock/Takeoff Return to Home /Landing Headless Mode (Short Press) Calibrating the Compass (Long Press) Antenna -08-... -
Page 13: Joystick Mode
JOYSTICK MODE MODE 2 (Left hand throttle MODE 2 will be the default setting.) Left Joystick Right Joystick Ascend Forward Descend Down Down Backward Left Right Left Right Fly to Fly to Rotate Rotate Right Left Left Right - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - MODE 1 To enter MODE 1, turn on the transmitter while holding the “Record Video”... -
Page 14: Preparation Before Flight Charging
PREPARATION BEFORE FLIGHT CHARGING USB Adapter Charging time: about Charging time: about (5V/2A) 220 minutes. 60 minutes. (Not included) (Charging) (Fully Charged) (Charging) (Fully Charged) Connect the USB charging cable to a USB Adapter(5V/2A), and then connect with the charging port of the drone or transmitter. - Before charging, please read the instructions in the “Use of Battery”... -
Page 15: Download App
PREPARATION BEFORE FLIGHT DOWNLOAD APP Android APP on Google play Scan the corresponding QR code and download the HT Drone app for free. Required Operating Systems: iOS 11.0 or later/Android 5.0 or later GIMBAL COVER ① Push the gimbal cover according to the arrow’s direction as shown above.(Pic.A) ②... -
Page 16: Drone Battery
PREPARATION BEFORE FLIGHT DRONE BATTERY Push the battery correctly into the drone battery compartment. Make sure that you hear a click sound, which indicates that the battery is firmly installed. Attention: The battery should be installed firmly. Otherwise, the flight safety of your drone may be affected. -
Page 17: Arm
PREPARATION BEFORE FLIGHT ARMS All arms of the drone are folded before the drone is packaged at the factory. First, unfold the front arms, then unfold the rear arms. TF CARD To store your photos and videos, insert the TF card (not included) into the slot as shown above before turning on the drone. -
Page 18: Propellers
PREPARATION BEFORE FLIGHT PROPELLERS HEAD ① An “A” “B” is printed on the propeller. ② Lock the propellers to the corresponding the arms of drone (the arms are also marked) with screws. ③ Rotate each screws clockwise. - The propeller is installed before the drone is packaged at the factory. -
Page 19: Antenna
PREPARATION BEFORE FLIGHT ANTENNA Before flying, please adjust the antenna on the back of the transmitter so it is facing outward. The signal between the drone and the transmitter is most reliable when the transmitter is positioned toward the drone, as depicted above on the left. If the transmission signal is weak during flight, adjust the orientation of the transmitter to ensure that the drone is within optimal transmission range. -
Page 20: Flight
2. Make sure the drone battery and the propellers are installed securely. 3. Make sure the drone arms are fully expanded. 4. Make sure that there is nothing obstructing the motors. 5. Make sure you use Holyton accessories. PAIRING HEAD ①... -
Page 21: Connect To Wi-Fi
Wi-Fi settings and click Wi-Fi to search for the Wi-Fi of the drone. (Make sure the pairing has finished before going to the Wi-Fi settings on your phone) ② Select the Wi-Fi network: HOLYTON—******. ③ Wait for a couple of seconds for your phone to connect to the drone’s Wi-Fi. -
Page 22: Calibrating The Compass
FLIGHT CALIBRATING THE COMPASS ① Long press the ( ) button, the transmitter will beep once, which indicates that the drone entered the compass calibration. ② Hold the drone horizontally and rotate it until the transmitter beeps once. ③ Hold the drone vertically and rotate it until the transmitter beeps twice, which indicates that the Compass Calibration is completed. -
Page 23: Gps Searching
FLIGHT GPS SEARCHING HEAD Place the drone on a flat and dry surface where is unobstructed and lit area. When the drone indicator lights turn solid green, the transmitter will send out a long beep, it means that the search for GPS signal is completed. This process may take about one minute. -
Page 24: Calibrating The Gyro
FLIGHT CALIBRATE THE GYRO Simultaneously push the left joystick and the right joystick to the bottom left corner to calibrate the gyro. The indicator lights on the drone will blink, then turn solid, which indicates that the calibration is completed. To ensure a stable flight, we suggest that the pilot calibrates the gyro every time after pairing the drone and after a crash. -
Page 25: Functions Details
FUNCTION DETAILS EMERGENCY STOP The Emergency Stop function should only be used in case of emergency during the flight to avoid any damage or injury. Long Press Long Press Press and hold the ( ) button and the ( ) button simultaneously for 2 seconds, the transmitter will beep continuously, and The drone will descend quickly to the ground. -
Page 26: Take Photo/Record Video
FUNCTION DETAILS TAKE PHOTO/RECORD VIDEO Take Photo: Short press the ( ) on the transmitter to take photos. The transmitter will beep once, which indicates that the camera has successfully taken one photo. Record Video: Short press the ( ) on the transmitter. The transmitter will beep twice, which indicates that the recording has started. -
Page 27: Headless Mode
FUNCTION DETAILS HEADLESS MODE The Headless Mode is a great training tool for beginner pilots. It is also useful when the drone is too far from the pilot (which makes it difficult to tell its orientation). It keeps the drone traveling forward, backward, left, or right when you move the right joystick in those directions, regardless of which way the front of the drone is pointed. -
Page 28: Return To Home(Rth)
FUNCTION DETAILS * Why is the orientation of the drone important? In normal flying mode, the control of the drone movement can sometimes be counter-intuitive for beginners. For instance, when the drone is in the air with its head pointing to your right, if you push the right joystick forward, the drone will fly to your right, instead of flying forward. - Page 29 FUNCTION DETAILS Smart RTH If the GPS signal is available (7 or more satellites reception) and the Home point is recorded previously. Press the ( ) button on the transmitter, then the drone will fly back to the Home Point automatically. Exit the RTH mode by pressing the ( ) button again.
- Page 30 FUNCTION DETAILS The First Stage of Low Voltage RTH The First Stage of Low Voltage RTH is automatically triggered when the Drone Battery Level icon will blink yellow on the APP, and the transmitter will beep continuously. The drone will fly back to the Home Point automatically. At this time, the pilot can take off the drone again and operate it within a safe range (Flight Altitude ≤...
-
Page 31: Stabilization Function
STABILIZATION FUNCTION AlTITUDE-HOLD FUNCTION The drone is designed with an altitude-hold function to maintain its altitude after releasing the left joystick. (The left joystick will automatically spring back to the middle) OPTICAL FLOW POSITIONING Vision Positioning Lens The Optical Flow Positioning System consists of a camera module, which acquires the position information of the drone through visual images to ensure precise positioning of the drone. - Page 32 STABILIZATION FUNCTION The Optical Flow Positioning System is typically used in an indoor environ- ment when the GPS signal is weak or unavailable. It works best when the drone altitude is less than 10 ft. ・The precision of the Optical Flow Positioning System is easily affected by the light intensity and features of the surface textures.
- Page 33 STABILIZATION FUNCTION ・Keep sensors clean at all times. ・The Optical Flow Positioning is only effective when the drone is within the altitude range of 10 ft. ・Make sure that the light is bright enough and the surface is with clear textures so that the Optical Flow Positioning can acquire the movement information through recognizing the ground textures.
-
Page 34: App Operation Instruction
APP OPERATION INSTRUCTION OPERATION INTERFACE Homepage: Tap this icon to return to the main menu. GPS Signal: Displays the current GPS signal strength. Wi-Fi Signal Strength: Displays the current signal strength between the drone and the mobile phone. Transmitter Battery Level: Real-time display of the current battery level of the transmitter. - Page 35 APP OPERATION INSTRUCTION VR: Tap to split the screen. Then place the mobile phone into a VR headset (not included) to watch the live feed in 3D. TapFly: Set any points on the map to draw the flight path, and then the drone will fly along this route.
-
Page 36: Beginner Mode
APP OPERATION INSTRUCTION BEGINNER MODE The default GPS mode is the beginner mode. When in this mode: 1. Flight Distance is limited between 0~98 ft. 2. Flight Altitude is limited between 0~98 ft. If you want to enter the anvanced mode, you need to exit the beginner mode by turning off the beginner mode as show below. -
Page 37: Specifications
SPECIFICATIONS DRONE Model: HT50 Weight: 245g/8.6oz Max Flight Time: 25 minutes (per battery) Operating Temperature Range: 14° to 104°F Size: 290 × 260 × 55 mm (Unfolded) 145 × 85 × 55 mm (Folded) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -... - Page 38 SPECIFICATIONS CAMERA Operating Frequency: 5500-5700MHz Photo Resolution: 4096×3072P (stored in TF card) 4096×3072P (stored on mobile phone) Video Resolution: 2688×1512P@25fps (stored in TF card) 1920×1080P@25fps (stored on mobile phone) Lens: FOV 120° Max Transmission Distance: 1640 ft (outdoor and unobstructed) Photo Formats: JPEG Video Formats: AVI/MP4 Supported TF Cards: Supports a TF Card (Class10 above) with...
-
Page 39: Contact Us
CONTACT US Please do not hesitate to contact us if you need further support. holyton@foxmail.com (USA) holyton_ca@foxmail.com (CA) holyton_eu@foxmail.com (EU) 4:00 PM ~ 7:00 AM (PST) For online support, please scan this code with Live Chat -35-... -
Page 40: General Information
(2) This device must accept any interference received, including interfer- ence that may cause undesired operation. Supplier's Declaration of Comformity Product Name: Quadcopter Model NO: HT50 Responsible Party: JL TRADING CO LTD Responsible Party Address: 5940 S RAINBOW BLVD STE 400-79525 LAS VEGAS, NV 89118... - Page 41 GENERAL INFORMATION WARNING: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. RF Exposure The equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This device should be installed and operated with minimum distance 20cm between the radiator &...
- Page 42 GENERAL INFORMATION (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionne- ment. CAN NMB-003 (B) RF Exposure Radiation Exposure Statement: The device is compliance with RF exposure guidelines, users can obtain Canadian information on RF exposure and compliance.
- Page 43 GENERAL INFORMATION BATTERY WARNING: 1. Failure to follow all the instructions may result in serious injury, irreparable damage to the battery and may cause a fire, smoke or explosion. 2. Always check the battery’s condition before charging or using it. 3.
- Page 44 We, Xiamen Huoshiquan Import & Export CO., LTD hereby, declare that the essential requirements compliance with the Directive 2014/53/EU, the RoHS Directive 2011/65/EU and Safety Directive 2009/48/EC have been fully fulfilled on our product with indication below: Product Name: REMOTE CONTROL MODEL/RADIO CONTROLLED Model/Mark: HT50/HOLYTON -40-...
- Page 45 GENERAL INFORMATION The Statement of compliance is available at the following address: http://www.holystone.com/Download/CE/HT50_EU_DOC.pdf This product can be used across EU member states. MANUFACTURER INFORMATION Manufactured by Xiamen Huoshiquan Import & Export CO.,LTD Address: Unit 1, Room 501, Hongxiang Building, No.258 Hubin Nan Road, Siming District, Xiamen, China +1(855) 888-6699 MADE IN CHINA(CN)
