Spartan Camera GOLIVE User Manual

4g lte trail camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
GOLIVE USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GOLIVE and is the answer not in the manual?

Questions and answers

Related Manuals for Spartan Camera GOLIVE

Summary of Contents for Spartan Camera GOLIVE

  • Page 1 GOLIVE USER MANUAL...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Activate Cell Service Setup and Registration Menu Settings Reference Photo Info Strip Test the Camera Camera Diagram Buttons Specifications General Information Legal Information...

  • Page 3: Activate Cell Service

    (Premium service required for video transmission.) You may purchase cellular service either from Spartan Camera (AT&T, Multicarrier, and Verizon models) or from your phone carrier (by adding it to your existing cell phone plan). Data service through Spartan Camera includes premium service at no additional charge.

  • Page 4: Setup And Registration

    SD card: Insert an unlocked SD card (name brand; up to 32 G (up to 128GB for GoLive); class 10; standard size, 80 MB/s or faster preferred, not microSD with or without adapter) into the SD card slot. Refer to the card symbol on the case for proper orientation.
  • Page 5 Input the code and tap Done. *If you are unable to download or access the Spartan Camera Mobile app then please proceed to the steps "Alternative Setup Using the Web Portal" below.
  • Page 6 3. Finalizing Camera Setup The following steps are optional, but we strongly recommend that you go through all of them before you deploy the camera. 1. Format the SD card. It is very important that you format the SD card in the camera before using it and it is a good idea to format it again every so often.
  • Page 7 If you have trouble updating the firmware over the air (either method above), then update it manually using the instructions in the How to update firmware Knowledge Base article linked on the Spartan Camera – User manual page. 4. Deploy Camera 1.
  • Page 8 Camera Setting Suggestions 1. Sensitivity This sets how sensitive the camera is to a difference in temperature between moving objects and the environment in its field of view. Typically it is best to set this to Low if the camera is in an environment colder than 40 °F, Normal for between 40 °F and 80 °F, and High for temperatures higher than 80 °F Please adjust this setting based on the current temperature in your location or where you'll be deploying/testing the camera.
  • Page 9 Alternative Setup For Cellular Models Using Web Portal 1. my.Spartancamera.com Account: a. Using a web browser on your computer or phone, go to www.spartancamera.com. b. Sign in to your account. If you don’t already have an account, register for one, then sign in under Camera Management.

  • Page 10: Menu Settings Reference

    Description Mode Photo, Video, or Photo + Video. Photo Size 4M or 8MP (GoLive 1&2) Photo: 1, 2, 3. Set the number of images taken for each trigger. The camera will transmit all photos when burst is 2 or 3.
  • Page 11 5 sec, 10 sec (320*200 or 1024*576) Video 1-30 seconds, selectable in 1-second increments (720P, Length 1080P). 5-30 sec in 5s intervals, 10s default Sound On/Off Off (turns off motion sensor) Low (temps below 10° F.) Sensitivity Normal (10° F-80° F) High (temps above 80°...
  • Page 12 server. Yes/No. Choose Yes to arm the camera immediately. You can also arm it by long pressing … in Preview mode and choosing Camera Yes. On if you want the photo info strip to show the date/time, Off if Time Stamp you don’t.
  • Page 13 Get the registration code needed to add the camera to your Code Premium account. Register Email Email address linked to your Spartan Camera account. Hello Test (to test connectivity) Module FW Update (tech support use only) Diagnostic APN Setting (tech support use only, not all models)

  • Page 15: Photo Info Strip

    F = Photo taken after format SD card request S = Requested photo (for the Take Photo Now command for GoLive and GoLive 2) G = GPS Accelerometer triggered photo (For GPS Enabled cameras when Camera Tracker option is turned ON)

  • Page 16: Test The Camera

    TEST THE CAMERA Photo, Send mode "Instant" 1. Press the OK button to take a picture. 2. Press the OK button to send the picture to the portal/app or the Menu button not to send the photo. Photo, Send mode "OFF" 1.
  • Page 17 Delete Photo or Video Warning! Deleted files cannot be recovered! 1. While viewing a photo or video, press Menu to access Delete Files. to be able to select either Delete Current File or Delete All Files. 2. Press ▲ or ▼ to select either Delete Current File or Delete All Files. 3.

  • Page 18: Camera Diagram

    CAMERA DIAGRAM...

  • Page 19: Buttons

    BUTTONS Menu ■ Preview mode: enter the Setup menu. ■ Setup mode (menus): Go back one menu level. (If in a submenu, return to the main menu. If at the main menu, exit Setup mode). ■ Playback mode: display the Delete menu so you can choose to Del One or Del ALL.
  • Page 20 ■ The camera will arm itself automatically after it stays idle in Setup mode for three minutes. Shortcuts in Preview mode: ■ selects Video mode. ▲ ■ selects Camera mode. ▼ ■ OK takes a picture or records a video manually. ■...

  • Page 21: Specifications

    SPECIFICATIONS Field of View 56° Display Screen 2’’ IPS LCD Display Screen Resolution 480*360 Send Mode Photo , Video , Photo + Video Image Resolution 4M, 8MP Image Aspect Ratio 16:9 Transmitted Image 800 * 480 (Normal) or 1376 * 768 (Large) Thumbnails HD Image (Upon request) 2688 * 1520 (4MP), 3840 * 2160 (8MP)
  • Page 22 Illumination Power Auto adjusted GPS & Mapping Supported Camera Tracker Available SIM Card Pre-installed Internal Power Supply Built-in Lithium-ion cell, 5300mAh External Power Supply 12 x AA (1.2v-1.5v ea.) , 12V DC , 12V Lead acid Solar Supported Direct-connect solar panel supported External Power Connection Included Product Warranty 2 years upon registration...

  • Page 23: General Information

    GENERAL INFORMATION Important: Please read the online documentation carefully before using your camera. Thank you for choosing the Spartan GoCam. The online documentation will help you get the most out of your new device. You will also find other technical articles and more information about your camera and using Premium service at: www.spartancamera.com.

  • Page 24: Warranty

    If a material or workmanship defect arises with regard to any Spartan Camera, and a valid claim is received within the Warranty Period, SC will (1) repair the camera using new or refurbished parts or (2) replace the camera with a new or refurbished product.

  • Page 25: Proof Of Purchase Or Proof Of Warranty Coverage

    RMA number. If a package is received after the RMA has expired, the warranty will be considered from the date it is registered with Spartan Camera. In addition, Spartan Camera reserves the right to charge a shipping and handling fee in connection with the fulfillment of any valid claim.

  • Page 26: Exclusions And Limitations

    evolving our designs to ensure our products do the best job possible. When requesting warranty coverage, we may require the following: a) Warranty registration within 30 days of the original purchase date, via mail in warranty card or online at the SC website is required for warranty coverage to be valid.
  • Page 27 services are being rendered. Wireless data plan management is solely the purview of the account holder and should be managed accordingly if warranty service is necessary. Warranty coverage is specifically limited to the original purchaser of the product and does not extend to any subsequent parties. Warranty coverage is exclusively limited to purchases made through an authorized dealer or retailer.

  • Page 28: Unclaimed Items

    Please allow 6-8 weeks for delivery. Camera Repair There will be a charge for repairs not covered by the warranty. Please contact Spartan Camera to determine more information and to discuss repair options not covered under warranty. PRIVACY POLICY Thank you for visiting www.spartancamera.com (the “Site”) and reviewing the...

  • Page 29: How Do We Use Your Email Address

    Please also read our Terms of Use. How Do We Use Your Email Address? Spartan Camera will use your email address to contact you to manage your account. For example, we may contact you via email in cases where your...

  • Page 30: Retention And Deletion

    ■ SC tries to protect your personal information and ensure the security of your communications on our systems, by maintaining physical, organizational and technological safeguards (appropriate to the sensitivity of such information) designed to protect it against unauthorized use, disclosure or access of the personal information we collect on this Site.

  • Page 31: Our Customers

    Site and the SC Services, you are agreeing to the Terms and Privacy Policy posted at the time of your visit. About Us Spartan Camera offers the Web Portal and associated Mobile Applications which are used to provide a premium function for the line of wireless cameras. Our Customers The Site is open to anyone, but some of the SC Services are only available to registered members (“Members”).

  • Page 32: Cost And Pricing

    Spartan Camera reserves the right to terminate your Membership at any time (even if you’ve paid), without warning for any or no reason, with or without prior notice or explanation and without liability and can even take legal action if needed.

  • Page 33: Content Limits

    Content Limits Spartan Camera continues to grow and get better because of users like you (Thank you!). Each camera that consumes a monthly Premium Service credit is provided with one month of photo uploads and other real time interactions using the web portal and mobile applications.
  • Page 34 Content. ■ If you stop using the Spartan Camera Services, your Content may remain on the Site unless you actively remove your Content. Photos will be purged after a 30-day retention period automatically.

  • Page 35: Limits On Use

    ■ It is also a violation to scrape the Site, fusker files, or otherwise make any use of data mining, robots or similar data gathering and extraction tools. ■ It is up to Spartan Camera whether to terminate your use for violation of these prohibitions or similar activities. Other Important Guidelines ■...
  • Page 36 ■ We encourage you to always keep backups of your Content. Spartan Camera is not responsible if any of your Content is deleted, or if any modification, suspension or discontinuation of the Site or services causes you to lose any Content—even if you’re a Paying Member.

  • Page 37: Things To Keep In Mind

    Site and Spartan Camera Services in violation of that...

  • Page 38: Image Delivery

    Spartan Camera. Spartan Camera assumes no responsibility for any errors that may appear in this document. In no event shall Spartan Camera be liable for incidental or consequential damages arising from use of this document or the software and hardware...
  • Page 39 This document and parts thereof must not be reproduced or copied without Spartan Camera written permission, and contents thereof must not be imparted to a third party nor be used for any unauthorized purpose. Contravention will be prosecuted. Additional or updated copies of this document may be obtained from the Spartan...
