Summary of Contents for AOBOCO ZF-FR-A05

  • Page 4: Product Introduction

    STATEMENT► Thank you for purchasing this product. In order to ensure the correct use of this product, please read the user manual carefully before use. Please keep this manual in a place where it can be easily founded at any time.If the current dangerous or unsafe operation is not avoided, it may result in death, serious personal injury or property damage.
  • Page 5 USAGE► Suitable for neck, shoulders, chest, back, arms, abdomen, waist, hips, knees, feet, elbows and other body parts. (Which parts of the body the product can be used on is determined by the characteristics of the product). CAUTIONS► 1. Read the user manual before use; 2.
  • Page 6 8. Pregnant women and patients with serious heart trouble who rely on pacemakers should consult doctors before use; 9. Do not fold the heating pad when using. Do not stack or cover anything on the heating pad when using; 10. DO not make any modifications to the switch button, wires and heating element. Unplug the heating pad when not in use;...
  • Page 7 WARNING► 1. It is forbidden to touch the electrical heating pad with wet hands, otherwise, it may cause electric shock and personal injury. 2. It is forbidden to use power beyond the specified value of the power supply or connected equipment. Using universal sockets or equipment that exceeding the specified value may cause the heating pad overheat, fire accidents, and personal injury.

  • Page 8: How To Use

    6. It is strictly forbidden to place obstacles or other metals on the heating pad, otherwise the heating pad may be exposed to severe heat, burns, sparks, etc., which may cause electric shock, fire, and personal injury. 7. It is forbidden to connect with unmatched heating elements. The controller is a single-wire variable frequency, constant temperature controller.
  • Page 9 it will automatically stop working when the time is up（A/B products are the same timer） 4. 122℉/50℃ button: under any temperature, press this button to switch directly to the temperature 122℉, this temperature is the most comfortable temperature. According to individual needs, press the temperature “-” “+” button to adjust the temperature （A/B products do not have this comfort function）;...

  • Page 10: Button Description

    BUTTON DESCRIPTION► Power ON/OFF button: power on display light up, power off display is off. Timer button: press “-” “+” button to adjust the time, while the time display will change. A/B products are the same timer. Temperature button: press “-” “+” to adjust the temperature, while the temperature display will change.
  • Page 14 ZF-FR-A05 (Adjustable A/B temperature) PRODUCT PARAMETERS Model No ZF-FR-A05 Knee Electric Heating Product Name Pads Voltage AC 110V/60Hz Power Temperature 86-158℉ Range Timing Range 10-90 Minutes Material Flannel （2PCS） You can use only one of them and just unplug another power cord.
  • Page 16 ZF-FR-A06 PRODUCT PARAMETERS Model No ZF-FR-A06 Neck Electric Heating Product Name Voltage AC 110V/60Hz Power Temperature 86-158℉ Range Timing Range 10-90 Minutes Material Flannel...
  • Page 18 ZF-FR-A07 PRODUCT PARAMETERS Model No ZF-FR-A07 Elbow Electric Heating Product Name Voltage AC 110V/60Hz Power Temperature 86-158℉ Range Timing Range 10-90 Minutes Polyester 100% Material (Super soft cloth) 1 PCS...
  • Page 20 ZF-FR-A08 PRODUCT PARAMETERS Model No ZF-FR-A08 Ankle Electric Heating Product Name Voltage AC 110V/60Hz Power Temperature 86-158℉ Range Timing Range 10-90 Minutes Polyester 100% Material (Super soft cloth) 1 PCS...
  • Page 22 ZF-FR-A09 PRODUCT PARAMETERS Model No ZF-FR-A09 Wrist Electric Heating Product Name Voltage AC 110V/60Hz Power Temperature 86-158℉ Range Timing Range 10-90 Minutes Polyester 100% (Super soft cloth) Material 1 PCS...
  • Page 24 ZF-FR-A11 PRODUCT PARAMETERS Model No ZF-FR-A11 Neck Electric Heating Product Name Voltage AC 110V/60Hz Power Temperature 86-158℉ Range Timing Range 10-90 Minutes Polyester 100% Material (Super soft cloth)
  • Page 26 ZF-FR-A13 (Adjustable A/B temperature) PRODUCT PARAMETERS Model No ZF-FR-A13 Product Name Electric Heating Mittens Voltage AC 110V/60Hz Power Temperature 86-158℉ Range Timing Range 10-90 Minutes Polyester 100% Material (Super soft cloth) 2 PCS You can use only one of them and just unplug another power cord.
  • Page 28 ZF-FR-A15 PRODUCT PARAMETERS Model No ZF-FR-A15 Neck Electric Heating Product Name Voltage AC 110V/60Hz Power Temperature 86-158℉ Range Timing Range 10-90 Minutes Material Polyester 100% (Super soft cloth)
  • Page 30 ZF-FR-A16 PRODUCT PARAMETERS Model No ZF-FR-A16 Product Name Heated Therapy Shoe Voltage AC 110V/60Hz Power Temperature 86-158℉ Range Timing Range 10-90 Minutes Polyester 100% (Super soft cloth) Material 1PCS...
  • Page 32 ZF-FR-A19 PRODUCT PARAMETERS Model No ZF-FR-A19 Plantar Fasciitis Product Name Heating Pad Voltage AC 110V/60Hz Power Temperature 86-158℉ Range Timing Range 10-90 Minutes Polyester 100% (Super soft cloth) Material 1PCS...

  • Page 34: Product Parameters

    ZF-FR-A20 (Adjustable A/B temperature) PRODUCT PARAMETERS Model No ZF-FR-A20 Electric Heated Bunion Product Name Corrector Voltage AC 110V/60Hz Power Temperature 86-158℉ Range Timing Range 10-90 Minutes Polyester 100% (Super soft cloth) Material 2 PCS You can use only one of them and just unplug another power cord.
  • Page 36 ZF-FR-A21 PRODUCT PARAMETERS Model No ZF-FR-A21 Ankle Electric Heating Product Name Voltage AC 110V/60Hz Power Temperature 86-158℉ Range Timing Range 10-90 Minutes Polyester 100% (Super soft cloth) Material 1 PCS...
  • Page 38 ZF-FR-A22 (Adjustable A/B temperature) PRODUCT PARAMETERS Model No ZF-FR-A22 Product Name Knee Electric Heating Pad Voltage AC 110V/60Hz Power Temperature 86-158℉ Range Timing Range 10-90 Minutes Polyester 100% (Super soft cloth) Material 2 PCS You can use only one of them and just unplug another power cord.
  • Page 40 ZF-FR-A23 PRODUCT PARAMETERS Model No ZF-FR-A23 Wrist Electric Heating Product Name Voltage AC 110V/60Hz Power Temperature 86-158℉ Range Timing Range 10-90 Minutes Polyester 100% Material (Super soft cloth) 1 PCS...
  • Page 42 ZF-FR-A24 (Adjustable A/B temperature) PRODUCT PARAMETERS Model No ZF-FR-A24 Product Name Electric Heating Mittens Voltage AC 110V/60Hz Power 100W Temperature 86-158℉ Range Timing Range 10-90 Minutes Polyester 100% (Super soft cloth) Material 2 PCS You can use only one of them and just unplug another power cord.
  • Page 44 ZF-FR-A25 PRODUCT PARAMETERS Model No ZF-FR-A25 Elbow Electric Heating Product Name Voltage AC 110V/60Hz Power Temperature 86-158℉ Range Timing Range 10-90 Minutes Polyester 100% (Super soft cloth) Material 2 PCS...
  • Page 46 ZF-FR-A26 PRODUCT PARAMETERS Model No ZF-FR-A26 Shoulder Electric Heating Product Name Voltage AC 110V/60Hz Power Temperature 86-158℉ Range Timing Range 10-90 Minutes Polyester 100% (Super soft cloth) Material 1 PCS...
  • Page 48 ZF-FR-A27 PRODUCT PARAMETERS Model No ZF-FR-A27 Product Name Electric Feet Warmer Voltage AC 110V/60Hz Power Temperature 86-158℉ Range Timing Range 10-90 Minutes Polyester 100% Material (Super soft cloth) The protective sleeve is removable.
  • Page 50 ZF-FR-A28 (Adjustable A/B temperature) PRODUCT PARAMETERS Model No ZF-FR-A28 Product Name Electric Heated Shoes Voltage AC 110V/60Hz Power 100W Temperature 86-158℉ Range Timing Range 10-90 Minutes Polyester 100% Material (Super soft cloth) 2 PCS You can use only one of them and just unplug another power cord.
  • Page 52 ZF-FR-A29 (Adjustable A/B temperature) PRODUCT PARAMETERS Model No ZF-FR-A29 Ankle Electric Heating Product Name Pads Voltage AC 110V/60Hz Power Temperature 86-158℉ Range Timing Range 10-90 Minutes Polyester 100% (Super soft cloth) Material 2 PCS You can use only one of them and just unplug another power cord.

This manual is also suitable for:

Zf-fr-a06Zf-fr-a07Zf-fr-a08Zf-fr-a09Zf-fr-a11Zf-fr-a13 ... Show all
