Page 7: Safety Instructions
WARNING Read this manual carefully before using the machine, for your own safety. SAFETY INSTRUCTIONS When using the machine,always abserve the enclosed safety instructions as well as the additional safety instructions. The following symbols are used throughout this manual: Denotes risk of personal injure or damage to the tools. ADDITIONAL SAFETY INSTRUCTIONS FOR PLANERS •... -
Page 8: Electrical Safety
• Do not use the machine for planing severely bowed or round wood. • Use the push block when approaching the cutters. • Use a support on both sides of the table when working long workpieces. • Always unplug the machine before performing any maintenance. •... - Page 9 • Rotate the cylinder (1 5) until the first cutter is visible. • Loosen the bolts (16) a few turns, into the direction as shown. • Remove the holder (17) with the cutter from the cylinder, into the direction as shown.
- Page 10 Adjusting the chamfering angle (fig. H) 。 ． The chamfering angle is infinitely variable between 0° and 45 • Slacken the screw (32) and turn the right-angle stop (33) out of the way. Re-tighten the screw. • Loosen the clamping lever (9). •...
- Page 11 • Remove the safety key (2). • The switch can be flip from ON to OFF. Can’t flip from OFF to ON. • Keep the safety key in a safe place. Circuit breaker (fig.L) In case of overload, the circuit breaker interrupts the circuit. •...
- Page 12 TECHNICAL DATA 110-120V~ 50/ 60Hz Voltage/Frequency 10A(1280W) Rate Power No-load speed 9000 /min Max. planing depth Max. planing width 156mm T able dimensions 156mm Weight 16.5 Kg Sound pressure level 98dB(A) Sound power level 111dB(A) (K=3 Take appropriate measures for the protection of hearing The sound levels stated are emission levels;...
-
Page 13: Parts Diagram
PARTS DIAGRAM... -
Page 14: Parts List
PARTS LIST Part No. Description Part No. Description Rivet Double head screw Angle label Wave washer Locking Nut T screw Spring card board Guide bar Adjustment screw Guide bar base Knob Washer Limit board (B) Spring washer Wave washer Bolt Bolt Bolt Angle pointer... - Page 15 Part No. Description Part No. Description Hex bolt Push board rubber Base Motor Sponge washer Self tapping bolt Bird mouth Air duct Damping washer Air duct (B) Cable clip Motor fixed plate Bolt Active pulley Switch shell Multi wedge belt Self tapping screw Bolt Six angle screw...
