PowerTec 71488 Instruction Sheet

INSTRUCTION SHEET
71488 Multi T-Track Fence with Laser Measure Right to Left, 3" High x 24" Long
71489 Multi T-Track Fence with Laser Measure Left to Right, 3" High x 24" Long
PACKAGING CONTENTS
1 - Multi T-Track Fence
TO USE
This Powertec Multi T-Track Fence can be use to create:
• General fixtures and jigs
• Router fences
• Drill press fences
• Miter gauge fence
SAMPLES OF HOW TO USE THE MULTI T-TRACK FENCE
Use the 71335 Multi track brackets with knobs
and T-bolts to attach the fence to fixtures
and T-Tracks.
QUESTION...
1•847•780•6120
The Multi T-Track Fence accepts a wide range of
accessory fasteners with 1/4'' T-bolts, 5/16'' T-bolts and
1/4'' hex bolts.
Powertec has these accessories (sold separately) to use
with the Multi T-Track Fence:
• 71335 - Multi track brackets with knobs and T-bolts
(1/4-20 by 1" long). Used to attach the fence to fixtures,
T-Tracks or another fence.
• 71367 - 3" flip stop. Turns the fence into an accurate
stop system.
• For usage ideas, refer to the Samples of How to Use
the Multi T-Track Fence
Router Table
Powertec 71335 L-Shaped
Multi Track Brackets
19-0612
