- Page 1 Vinowake TrioVino: Aerator, Dispenser & Vacuum Preserver User Manual...
- Page 2 11-09-2023. At the time of purchase, there may be an updated version available. For the latest For the setup version of the video manual: https://linkstyle.life/vw55 If you need any support, don't hesitate to reach out to us at: email: support@linkstyle.life voicemail: 1-888-419-4888...
-
Page 3: Table Of Contents
Table of Contents A. Notice Before Use..........4 B. Product Overview..........6 C. Setup & Installation..........8 D. Operating Instructions........10 E. Error Handling...........15 F. Maintenance & Care.........16 G. Technical Specifications........18 H. Warranty & Support........19... -
Page 4: Notice Before Use
A. Notice Before Use Make sure to charge the device with the provided magnetic charger before using it. This device charges from empty to full in approximately 3 hours. We suggest that you run clean water through this device before first use. This device is designed to create a vacuum seal on a standard wine bottle and will only draw water through the tube and spout in a sealed... - Page 5 A. Notice Before Use (Continued) Due to the indented shape of most wine bottles, a fully dispensed bottle of wine will still contain 1 to 2 ounces of wine at the bottom. This device is designed to fit most wine bottles. There may be a few bottles with non-standard shapes that this device may not be compatible with.
-
Page 6: Product Overview
B. Product Overview Touch Sensitive LED Display Tube Spout Dust Cover Filter Mesh Dust Cover Magnetic Charging Connector Start Button + Button - Button Dispense Button... - Page 7 B. Product Overview The Vinowake TrioVino is a multi-function device designed to provide a seamless wine- drinking experience. Its functions are: Dispenser: Dispense a preset volume of wine from the bottle with the press of a button Aerator: As the wine is drawn and dispensed...
-
Page 8: Setup & Installation
C. Setup & Installation Charge the device Plug the Magnetic Charging Cable into a USB charging outlet and use the magnetic connectors to charge the device. The battery indicator on the LED Display will show 100% once it is fully charged. Magnetic Charging Connectors... - Page 9 C. Setup & Installation (Continued) Assemble the device Install the Dispenser Tube by inserting the tube end into the tube cap on the main unit. Open the bottle of wine and insert the device into the bottle tube first. Gently press the device down over the mouth of the bottle.
-
Page 10: Operating Instructions
D. Operating Instructions Wake up the device Tap the Start Button to wake up the device. If the device is turned off, press and hold the Start Button until it turns on. - Page 11 D. Operating Instructions Vacuum seal the bottle Double tap the Start Button while the device is awake (Display is on) to draw out air and create a negative pressure vacuum seal of -50 kPa. Note: The device will check the air pressure in the bottle every 10 minutes.
- Page 12 D. Operating Instructions (Cont.) Set dispense volume Press the + and - Buttons to set and view the volume. The volume will be shown on the LED Display in mL. The dispense volume can be set between 50mL and 999mL.
- Page 13 D. Operating Instructions (Cont.) Dispense wine Hold the wine glass up to the Spout. Double press the Dispense Button to dispense wine automatically. Do not remove glass from spout until the device has finished dispensing. To terminate the dispensing process before it has stopped, press the Start Button...
- Page 14 D. Operating Instructions (Cont.) LED Display screens The LED Display automatically cycles between 3 screens while it is awake, and goes to sleep in 30 seconds if no action is taken. Temperature Indicator Vacuum Saver Battery Indicator Pressure Display...
-
Page 15: Error Handling
E. Error Handling Turn the device on Turn the device on and off (press and and off, and make hold the Start sure to fully charge Button) when you the device before see the Err code. use if you see EO1. Press and hold the - Charge the device Button for 5 seconds... -
Page 16: Maintenance & Care
F. Maintenance & Care Cleaning Clean and dry this device immediately after use. Do NOT use detergents to clean the inside of this device. For better cleaning effect, use a small amount of lemon juice or vinegar when rinsing the device. Fill an empty wine bottle with clean water. - Page 17 F. Maintenance & Care (Cont.) Storage Store this device in its original product packaging for maintenance when not in use.
-
Page 18: Technical Specifications
G. Technical Specifications Dimensions Height: 6.14 in. (156mm) Width: 2.36 in. (60mm) Depth: 5.19 in. (132mm) Net Weight: 9.98 oz (283g) Power Source Battery Type: Li-ion 3.7V Battery Capacity: 900 mAh Charge Time: Approx. 3 hrs Dispense Volume Approx. 8L on a full charge Vacuum Pressure -50 kPa Wine Preservation... -
Page 19: Warranty & Support
This Product Warranty Agreement ("Warranty") applies to items purchased directly from Linkstyle. Warranty Duration: All products sold by Linkstyle come with a standard one (1) year warranty from the date of purchase, unless stated otherwise. Warranty Coverage: During the warranty duration, Linkstyle assures that the product will be free from defects in materials and workmanship when used under regular conditions. - Page 20 Our team will evaluate the claim and, if required, provide return shipping instructions. If the product is confirmed defective, Linkstyle, at its discretion, will repair or replace the item. Limitation of Liability: Linkstyle's liability is strictly limited to the repair or replacement of the product.
- Page 21 Apple and Apple logos are trademarks of Apple, Inc., registered in the U.S. and other countries. App Store is a service mark of Apple, Inc. Amazon, Alexa, and all related logos are trademarks of Amazon.com Inc. or its affiliates. Google and Google Play are trademarks of Google LLC. Other third-party brands and names are the property of their respective owners.
- Page 22 Linkstyle.life Unlocking the enchanted life!
