Maker Hart JUST MIXER S Owner's Manual

*G6047120R0-00*
JUST MIXER S
Thank you for purchasing JUST MIXER S. For
best performance and to ensure that it is used
correctly, please read this user's guide before
using the product.
■
Features
USB or battery power mode
It can be powered by 5V / 1A USB or 1.5V
battery (AAA).
Stereo 3 input / 2 output
It can connect 3 audio inputs at the same time.
Each track has an independent volume
adjustment knob, which can be output by
headphones and speakers.
Ultra-small mixer
Easy to operate and easy to carry.
■
Specifications
Gain Dimensions
25dBm 100 x 55 x 15 mm/
Current consumption 3.9" x 3.1" x 0.6"
70mA (max) Weight
Power supply 70 g / 2.5oz (body)
USB 5V/1A power or
1.5V battery (AAA)
■
Accessories
USB Cable x 1
3.5 to 3.5 audio cable x 1
1.5Vbattery(AAA) x 2 (Alkaline battery-Use About 15 hours)
dust bag x 1
Owner's Manual x 1
■
Operation
1.
Connect headphone/ speaker and audio input.
2.
Connect USB power /1.5Vbattery(AAA).
3.
Turn on the power switch.
4.
Adjust the volume for each channel in
use and master volume.
G 6 0 4 7 1 2 0 R 0 - 0 0
Owner's Manual
■
Panel Function
Audio Output
Headphones Jack
3.5mm stereo output
USB Cable
Channel Volume
Knob
Adjusts volume control
for each channel
Master Volume Knob
Power Indicator
Battery: Green light
USB: blue light
Audio input
Connect 3.5mm
external sound source
3 Segment switch
USB/OFF/battery
■
Important Notes
Notes Concerning Batteries
If you heard noise, it may because battery power is
running low. Please replace the battery.
The life of the supplied batteries may be limited, since
its primary purpose was to enable testing.
When installing or replacing batteries, always turn this
unit off and disconnect any other devices you may
have connected. This way, you can prevent malfunc-
tion and damage.
If used improperly, batteries or rechargeable batteries
may explode or leak and cause damage or injury. In
the interest of safety, please read and observe the
following precautions.
+ +
AAA AAA
Carefully follow the installation instructions for
- -
batteries, and make sure you observe the correct
polarity.
1.5Vbattery(AAA)
Remove the batteries whenever the unit is to remain
unused for an extended period of time.
Used batteries must be disposed of in compliance
with whatever regulations for their safe disposal that
may be observed in the region in which you live.
About Power Sources
We recommend that the power source not be used
together with other devices in order to prevent noise.
Before connecting other devices, please disconnect
the power of all other devices in order to avoid
causing damage to the product or its functions.
Do not use a shared circuit power supply with a
device that generates line noise, such as electric
motors or lighting systems with dimmer functions.
Do not step on or place heavy objects on the power
cord to avoid damaging it.
When unplugging the power supply, hold the head of
the plug and do not pull the cord itself.
Battery case
If the device is not going to be used for a period of
time, please disconnect the power.
1.5V battery
Maintenance
To clean, wipe with a soft dry cloth or a damp
cloth. To remove stubborn stains, use a mild,
non-corrosive cleaning agent. Be sure to use a
soft dry cloth to wipe the device dry.
Do not use benzene, thinner, alcohol or any type
of solvent to prevent the possibility of discolor-
USB Power
ation or deformation.
USB 5V/1A
Storage
Do not leave this device in an environment
subject to extreme temperatures, such as a
closed vehicle under direct sunlight.
Avoid using the product in dusty, humid or
high-vibration environments.
Using this device near a loudspeaker or other
device connected to a large power source will
easily cause noise.
Extra Precautions
Turn off the power and disconnect the USB 5V/1A
Adaptor adapter from the electrical outlet immediate-
ly if:
The USB power adapter or power cord is
damaged;Smoke or smell is detected.
If any external object is inserted into the device, or if
the device comes into contact with liquid.
The device is not functioning properly or the
performance has changed significantly.
