Crest Audio N-CODER Specifications

Product Information
The hand-held N-Coder is an economical, easy to use program-
mer, capable of configuring Crest Input Processing NC Modules.
It is designed for use when an NC-NXS NexSys
is not installed in the CK family power amplifier.
When plugged into an Input Processor Module, N-Coder auto-
matically identifies the module type and displays only the para-
meters available for that module. The user can then adjust para-
meters, audition the results, then store the new settings in the
module's non-volatile memory. Settings can also be stored inside
N-Coder for later reference.
A module does not need to be powered, or even be installed in the
amplifier for programming; N-Coder provides the necessary
power. Processing parameters can also be created ahead of time
without any modules attached, stored in the N-Coder, then down-
loaded into the modules later.
el Output Power Model Output Power
me @70.7V Name @8 /Ch.
CKS 100 50W
100 50W
CKS 200 100W
200 100W
CKS 400 200W
400 200W
CKS 800 400W
800 400W
CKS 800-2 400W
600 800W
CKS 1200-2 600W
400 1200W CKS 1600-2 N-Coder
800W
Data
Port
Designed & manufactured in the USA by:
Model
CC-BLK
Crest Audio Inc.
100 Eisenhower Dr.
Paramus, New Jersey 07652 USA
S P E C I F I C AT I O N S
Display:
Connectors:
Power Source:
Controls:
® network module
Out A Out B
5
Level 4
6
A 3
7
2
8
1
9
0
10
HP LP
HP LP
Level 5
4
6
B
3
7
2
8
1
Input A Input B 9
0 10
Model
NC-SCO
+ +
– –
Power
Processing
Control
N-CODER
Every Crest Input Processing Module can be programmed from a
hand-held N-Coder except for DSP modules. DSP, with its exten-
sive processing options, requires N-Coder/PC or LCP-AC8 (Octo-
pus) software.
The N-Coder can be powered from a common 9VDC battery or
the supplied 12VDC wall adapter. It communicates with Input
Processing Modules using an RJ-14 cord (supplied).
Features
• Offers a level of physical security:
- Settings are out of the reach of prying hands
- Ideal for troubleshooting installs
• Program & store settings internally, indefinitely
• Input Processing Modules can be programmed or reviewed on
site, in rack, in or out of amplifier.
RJ-14 jack connection to NC module (cable supplied)
12V DC external power input (supplied), or 9V battery
On/off switch and panel buttons (menu, value, enter)
READING DEVICE:
NC-SCO
2 x 16 character LCD window
