Crest Audio MM 623 PROGRAM AUDIO MIXER Specifications
Crest Audio MM 623 PROGRAM AUDIO MIXER Specifications

Crest Audio MM 623 PROGRAM AUDIO MIXER Specifications

Commercial series program audio mixer

Advertisement

Quick Links

Crest Audio reserves the right to make improvements in manufacturing or design which may affect specifications.
9/5/01
v.1.5
*A4500019*
Crest Audio Inc.
16-00 Pollitt Dr. Fair Lawn, NJ 07410
TEL: 201.909.8700 FAX: 201.909.8744
www.crestaudio.com
Output Specifications:
Min Load
Output
Impedance
Nom
Left/Right
600 Ohms
+4 dBu
Aux
600 Ohms
+4 dBu
0 dBu = 0.775 V (rms) 0 dBu = 1 mW
Features
• six balanced mic/line inputs (transformer optional )
• mic/line inputs assignable per channel to L,R and
Aux buses
• channel one mute capability, variable threshold
• two selectable RCA stereo or mono line inputs
• three electronically balanced line outputs: Master
L, R and Aux
• four-band EQ on Master L, R out
• remote Master level control
• euro style I/O connectors
• 48 VDC phantom power, selectable per channel
• remote stereo input select or remote stereo mute
MM
TM
623
Program Audio Mixer
S E R I E S
Output Level
Balanced
Max
UnBalanced
+21 dBu
Balanced
+19 dBm
+21 dBu
Balanced
+19 dBm
Description
The MM 623 is a versatile, high quality mixer
designed with the professional in mind. Offering six
microphone inputs, two selectable stereo inputs,
and such features as bus assignment, phantom
power, remote master, Left, Right, and Aux out-
puts, this compact unit is perfectly suited to mod-
ern diverse applications. All inputs and outputs are
electronically balanced. Equalization is performed
by an active, four-band, fixed frequency stereo EQ.
There are three five-segment LED meters moni-
toring each of the main outputs.
Each of the microphone inputs has switchable
phantom power and a 20 dB pad for line level sig-
nals. Channel one has a variable threshold for
ducking all other inputs. The unit offers remote
select of the two stereo inputs. The unit can also
be set as master or slave and all audio and control
buses are linkable. All connections are offered on
pluggable Euro connectors. The MM 623 offers a
multitude of features in one EIA rack space.
Connector
+
-
Ground
+
-
Ground
