Summary of Contents for AVLT AVLT-DM09-1
- Page 1 INSTALLATION MANUAL Aluminum Single Arm Gas Spring Extend Wall Mount 32" AVLT-DM09-1 75x75/100x100 1~8kg (2.2~17.6lbs) RATED AP4-0039A ±90° +35° -35° ±180° ±180° ±90°...
- Page 2 M4x12 (x4) M5x16 (x4) D5 (x4) M4x16 (x4) M5x12 (x4) B (x1) C (x1) M-F (x4) 6mm (x1) A (x1) D (x3) W-A (x3) W-B (x3) W-C (x3) 55mm (2. 2 ") ø 4.5mm (ø 3/16") √ 60mm (2. 4 ") ø10mm (ø...
