Seagate ST250DM000 Product Manual page 5

Figure 1. Typical 5V startup and operation current profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Figure 2. Typical 12V startup and operation current profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Figure 3. Serial ATA connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Figure 4. Attaching SATA cabling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Figure 5. Mounting dimensions for 750-200 GB models (except ST3250410AS and ST3250310AS) . 43
Figure 6. Mounting dimensions for 160-40 GB models (including ST3250410AS and ST3250310AS) 44
Barracuda 7200.10 Serial ATA Product Manual, Rev. K
List of Figures
iii
