Red - 12v Input (This is the power source)
Blue -12v Output (This is the device you are filtering)
Black - Ground
Ground
12v Input
12v Output
Installation Instructions
These steps apply to the IBNF5, IBNF10, IBNF30, IBNF40 and IBNF50.
Electronic Device
A battery is shown for reference, the IBNF can be connected
to constant or switched power sources.
8/14/21
