Lil' Jumbl LILJUMRESKITCH User Manual

Wooden 5-star diner playset with cash register and built-in seating
Hide thumbs

Advertisement

Table of Contents

Wooden 5-Star Diner Playset with Cash
Register and Built-In Seating
SKU: LILJUMRESKITCH
User Guide
Thank you for purchasing the Lil' Jumbl Wooden 5-Star Diner Playset with Cash Register
and Built-In Seating. This User Guide is intended to provide you with guidelines to ensure
that operation of this product is safe and does not pose risk to the user. Any use that
does not conform to the guidelines described in this User Guide may void the limited
warranty.
Please read all directions carefully before using the product and retain this guide for
reference. This product is intended for household use only. It is not intended for
commercial use.
This product is covered by a limited one-year warranty. Coverage is subject to limits and
exclusions. See warranty for details.
WARNING:
-
CHOKING HAZARD
Small parts
Not for children under 3 years.
WARNING:
Adult assembly required. Keep away
from children when assembling.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LILJUMRESKITCH and is the answer not in the manual?

Questions and answers

Related Manuals for Lil' Jumbl LILJUMRESKITCH

Summary of Contents for Lil' Jumbl LILJUMRESKITCH

  • Page 1 Wooden 5-Star Diner Playset with Cash Register and Built-In Seating SKU: LILJUMRESKITCH User Guide WARNING: CHOKING HAZARD Small parts Not for children under 3 years. WARNING: Adult assembly required. Keep away from children when assembling. Thank you for purchasing the Lil’ Jumbl Wooden 5-Star Diner Playset with Cash Register and Built-In Seating.

  • Page 2: Safety Precautions

    Safety Precautions Please read all safety precautions and instructions carefully before using this product. WARNING Failure to properly follow the guidelines established here could result in serious injury. This product is not recommended for children under 3 years old. WARNING Choking hazard –...

  • Page 3: Package Contents

    Package Contents...
  • Page 4 Package Contents (continued)
  • Page 5 Package Contents (continued)

  • Page 6: Package Contents Hardware

    Package Contents (continued) Hardware Accessories Recommended Tools • Allen wrench • Wrench • Philips-head screwdriver (included) (included) or electric screwdriver (not included)
  • Page 7 Assembly Instructions Attention: It is recommended to assemble this product with at least two (2) people. Step 1 • Fasten four (4) L inlet latches to doors 16, 17, 20, and 21 using eight (8) J screws, two (2) screws for each inlet latch.
  • Page 8 Step 2 • Fasten two (2) K outlet latches to panels 12 and 14 using four (4) J screws, two (2) screws for each outlet latch. DO NOT...
  • Page 9 Step 3 • Fasten two (2) K outlet latches to panel 13 using two (2) pairs of F screws and hex nuts. DO NOT...
  • Page 10 Step 4 • Fasten handle 31 to door 17 using two (2) C screws. Then, fasten handles 30 to doors 20 and 21 using four (4) C screws, two screws for each handle.
  • Page 11 Step 5 • Remove the tab sticking out of the battery compartment of ice dispenser 36. Then, insert ice dispenser 36 into door 21. Remove the plastic tab from the back of the ice dispenser.
  • Page 12 Step 6 • Flip the switch to the ON position under the two (2) burners 29. Then, fasten burners 29 to countertop 22 using six (6) G screws. Flip the switch to the "ON".
  • Page 13 Step 7 • Remove the tab sticking out of the battery compartment of faucet 33. Then, fasten faucet 33 to countertop 22 using two (2) G screws. Remove the plastic tab from the back of the faucet.
  • Page 14 Step 8 • Insert inner plastic loops into stove knobs 32. Then, insert the stove knobs 32 into panel 19. Finally, add clips onto the back of the stove knobs in the back of panel 19.
  • Page 15 Step 9 • Fasten three (3) hooks 35 to panel 28 using three (3) H screws. NOTE: Make sure the end of hooks 35 face out towards the finished side of panel 28 when fastening the hooks.
  • Page 16 Step 10 • Fasten panel 1 to panel 2 using two (2) A screws.
  • Page 17 Step 11 • Fasten panel 8 to panel 2 using two (2) A screws.
  • Page 18 Step 12 • Fasten panel 5 to panel 1 using two (2) A screws.
  • Page 19 Step 13 • Fasten panel 7 to panel 5 using two (2) A screws. NOTE: When installing panel 7, make sure the holes for the E dowel nuts are facing down, postioned on the underside of the panel.
  • Page 20 Step 14 • Fasten panel 7 to panel 2 using two (2) D screws and two (2) E dowel nuts. Use the allen wrench if needed. NOTE: When using E dowel nuts, make sure to insert E dowel nuts into the hole first before inserting the screw.
  • Page 21 Step 15 • Fasten panel 6 to panel 8 using two (2) A screws.
  • Page 22 Step 16 • Fasten panel 9 to panel 6 using two (2) A screws. NOTE: When installing panel 9, make sure the holes for the E dowel nuts are facing down, postioned on the underside of the panel.
  • Page 23 Step 17 • Fasten panel 9 to panel 2 using two (2) D screws and two (2) E dowel nuts. Use the allen wrench if needed. Allen wrench (included)
  • Page 24 Step 18 • Fasten two (2) panels 3 to panel 2 using four (4) A screws.
  • Page 25 Step 19 • Fasten panel 4 to panels 3 using two (2) A screws. NOTE: When installing panel 4, make sure the holes for the E dowel nuts are facing down, positioned on the underside of the panel.
  • Page 26 Step 20 • Fasten panel 4 to panel 2 using two (2) D screws and two (2) E dowel nuts. Allen wrench (included)
  • Page 27 Step 21 • Insert six (6) M wooden pegs into panel 11.
  • Page 28 Step 22 • Fasten panel 11 to panels 1 and 8 using one (1) A screw. NOTE: Make sure the black strip on panel 11 is facing outward before fastening the part in place.
  • Page 29 Step 23 • Insert two (2) M wooden pegs into panel 10. Then, fasten panels 12 and 13 to panel 10 using four (4) A screws. NOTE: Make sure the cutout corner on panels 12 and 13 are facing outward and the mounted piece on panels 12 and 13 are facing each other before fastening the parts in place.
  • Page 30 Step 24 • Place panel 10 on the M wooden pegs in panel 11. Then, fasten panel 10 to panels 1 and 8 using four (4) A screws. And use one (1) more A screw to fasten panel 1 to panel 11.
  • Page 31 Step 25 • Fasten panels 12 and 13 to panel 2 using four (4) B screws.
  • Page 33 Step 27 • Place door 16 in between panels 1 and 12. Then, fasten panel 14 to panels 1 and 12 using four (4) B screws.
  • Page 34 Step 28 • Insert four (4) M wooden pegs into panel 18. Then, place panel 18 on panel 14.
  • Page 35 Step 29 • Place door 17 on panel 14.
  • Page 36 Step 30 • Place panel 15 in between panels 12 and 13.
  • Page 37 Step 31 • Place door 20 in between panels 12 and 13.
  • Page 38 Step 32 • Place door 21 in between panels 13 and 8.
  • Page 39 Step 33 • Insert four (4) M wooden pegs into panel 19. Then, align all the hinges and pegs so panel 19 can be properly placed onto the main assembly.
  • Page 40 Step 34 • Fasten panel 19 to panels 1 and 8 using two (2) A screws.
  • Page 41 Step 35 • Fasten panel 19 to the rest of the assembly using two (2) B screws...
  • Page 42 Step 36 • Fasten panels 26 and 27 to countertop 22 using four (4) A screws.
  • Page 43 Step 37 • Fasten panel 25 to panel 27 using two (2) A screws.
  • Page 44 Step 38 • Fasten panel 23 to panel 26 using two (2) A screws.
  • Page 45 Step 39 • Fasten panels 23 and 25 to countertop 22 using four (4) B screws.
  • Page 46 Step 40 • Fasten panel 28 to panel 23 using two (2) B screws.
  • Page 47 Step 41 • Place countertop 22 on the main assembly and fasten it down using four (4) A screws and four (4) B screws. NOTE: If countertop 22 doesn’t fit in the first time, loosen screws in panel 8 to fit countertop 22 in place.
  • Page 48 Step 42 • Fasten sign 24 to panels 23 and 25 using four (4) I screws.
  • Page 49 Step 43 • Place sink 34 into the opening of countertop 22.
  • Page 50 Step 44 • Add accessories to the finished assembly.

  • Page 51: Specifications

    Specifications Product type: Diner playset Product length: 36.6'' Product width: 23.2'' Product height: 43.3'' Packaging length: 44.5" Packaging width: 26.4" Packaging height: 5.9" Weight: 57.7 lbs Material: MDF Color/finish: Multicolored Drawers included: No Doors included: Yes Number of doors: 4 Shelves included: Yes Number of seats: 2 Turnable knobs included: Yes...
  • Page 52 Product; (b) Damage caused by use with non-Lil' Jumbl Wooden 5-Star Diner Playset with Cash Register and Built-In Seating product; (c) Damage caused by accident, abuse, misuse, flood, fire, earthquake, or other external causes;...
  • Page 53 This Warranty is valid only in the country where the consumer purchased the Product, and only applies to Products purchased and serviced in that country. The Company does not warrant that the operation of the Product will be uninterrupted or error-free. The Company is not responsible for damage arising from your failure to follow instructions relating to its use.
  • Page 54 Questions or comments? Contact Us! 866-849-3049 info@liljumbl.com LIL JUMBL and the LIL JUMBL LOGO are trademarks of C&A IP Holdings LLC in the US. All other products, brand names, company names, and logos are trademarks of their respective owners, used merely to identify their respective products, and are not meant to connote any sponsorship, endorsement, or approval.
