Summary of Contents for Profihantel WTD-005
- Page 1 Multi-Function Home Gym Weight Bench USER MANUAL warning: MAX 600 LB...
-
Page 2: Exploded Diagram
I. EXPLODED DIAGRAM... -
Page 3: Parts List
II. PARTS LIST Name Name Quantity ntity screw bolt screw bolt （M8x80） （M10x70） Fixing Washer Fixing Washer （Ø8） （Ø10x30） Fixing Nut Hexagon Wrench （M8） （M6） With ring Open-end Wrench plug-in （13-15） screw bolt Hexagon Wrench （M8x25） （M8） Matte bell Open-end Wrench sheet fixed （14-17）... - Page 4 III. ASSEMBLY INSTRUCTIONS 1-1. Take the Main Frame[1] out, Secure the Support Tube[2] on Main Frame[1] with Fixing Screw[3], Large Washer[4] and Fixing Nut[5], then Insert With ring plug-in[10]. 1-2. Please remove the pre-installed screws & nuts, Secure the Bottom Tube[7] on Support Tube[2], and tighten the screws[6].
- Page 5 Front hook foot tube 2-1. Attach [8] to Support Tube[2], and install the outer hole Fixing Screw[3], Large Washer[4], Screw Cap[5]; With ring plug-in[10] to the inner hole. Note： that the high side of the hole is in front when installation Leg curl tube 2-2.
- Page 6 Adjustable 3-1. Install Bar [11] to Preacher Pad [12] and then secure it with the Fixing Screw[13] and Fixing Washer[4]. Assembly 3-2. Then insert Preacher Pad into Support Tube[2] installed in Step 2. Align the holes and tighten the Pull pin knob[14]. Note:14 are already pre installed on the 2...
- Page 7 4.The leg tube 18 is connected with the connecting tube numbered 19 using bolts 16 and washers 17，and tighten screws.
- Page 8 5-1.Install the stand pipe numbered 23 onto the leg pipe numbered 18, using the bolt numbered 20, the washer numbered 21, and the cap nut numbered 22; Pay attention to the installation direction of No. 23; Note:20 and 21.22 are already pre installed on the 8 5-2.Install the connecting pipe No.
- Page 9 6 . Insert the in the mount Adjustable Barbell Components (26) on the Rear Frame assembly（23）, as shown in figure（25） Note: 25 are already pre installed on the 23...
- Page 10 7-1. Install the main rack installed in the front section to the rear rack section, connect it with bolts 6, washers 4, and nuts 5, and then tighten it with a wrench； Note: 4 5and 6 are already pre installed on the 19 7-2.Install the rubber wool 27 into the front circular tube...
- Page 11 8. Final Inspection Please inspect your exercise equipment to ensure that all fasteners are tight and components are properly assembled. Review all warnings affixed to machine. Congratulations! You have successfully completed assembly and installation of your equipment !
-
Page 12: Important Safety Instructions
IV. IMPORTANT SAFETY INSTRUCTIONS WARNING: Read all instructions before using this product. Please always keep this manual with you. • This equipment is designed for indoor and family use only. • The equipment is not suitable for therapeutic use. • It is important to read this entire manual before assembling and using the equipment. Safe and effective use can only be achieved if the equipment is assembled, maintained, and used properly.
