Danco 62069 Installation Instructions

B
Image I
Duct Opening
Length (C)
Floor
Instructions
Tools Required: Screw & Screwdriver (Not provided with kit)
1. Refer to your OEM instructions on how to safely remove the old floor register.
2. Remove your old floor register (A) and discard. Do not discard the old screws (B).
3. Measure your floor duct opening size (C).
4. Select the appropriate floor register for your need. Danco offers 4 different sizes.
Always choose a size slightly bigger than the duct opening itself. For example, if your
duct size is 3 ½" X 9 ¼" then choose the 4" width X 9 ¾" length (62068).
5. Install new register into your floor opening using the screws as shown on Image I.
Note: Some ducts don't require the screws to hold register in place. If your duct opening
doesn't have screw holes, then simply set the register into the floor opening.
6. Adjust the damper handle as desired.
INSTALLATION INSTRUCTIONS FOR
FLOOR REGISTER AND GRILLE
A
Damper Handles
Duct Opening
Width (C)
Overall front
size (Length)
Floor register
opening (Length)
Note: is dimension is what goes
into the oor duct opening
Danco Actual floor opening size
62067 4" width x 7-3/4" length
62068 4" width x 9-3/4" length
62069 4" width x 7-3/4" length
62070 3-3/4" width x 9-7/8" length
Overall front
size (Width)
Floor register
opening (Width)
Overall front size Depth
5-3/8" width x 9-3/8" length 0.85"
5-3/8" width x 11-3/8" length 0.85"
5-3/8" width x 10-1/8" length 1.37"
5-3/8" width x 12-1/8" length 1.37"
©2022 Manufactured for
Danco, Inc., Irving, TX 75062
62067i/62068i/62069i/62070i
