RLK12- 5 0 0 WB4
5MP 12CH Dual-Band Wi-Fi
Surveillance System, 12-
Channel NVR with 1TB HDD,
4pcs of 5MP Cameras,
Inte lligent Detection, 24/7
Recording, IP67 Weatherproof
Rating, and More.
• 5MP HD with Dual-Band WiFi
• Person/Vehicle/Animal Detection
• 12-Channel NVR Recorder with 1TB HDD
Video & Audio
Image Sensor
Resolution
Lens
Video Compression
Field of View
Day/Night Mode
NightVision
Frame Rate
Code Rate
Spec iica tion s
1/2.7" CMOS Sensor
2560 x 1920 (5 megapixels) @20fps
f=4.0 mm ixed; F=2.0, with IR Cut
H.264/H.265
Horizontal: 80 °; Diagonal: 100 °; Vertical:
42°
Auto-switching
Up to 30 meters (100ft) ; LED: 18 pcs/
1 4 mil/ 8 5 0 nm
Mainstream: 2fps–20fps (Standard:
20fps); Sub stream: 4fps–15fps
(Standard: 10 fps)
Mainstream: 1 0 2 4 Kbps– 5 1 2 0 Kbps
( Standard: 40 9 6 Kbps); Sub stream:
64 Kbps–512Kbps (Standard: 256Kbps)
Advertisement
Related Manuals for Reolink RLK12-500WB4
Summary of Contents for Reolink RLK12-500WB4
- Page 1 RLK12- 5 0 0 WB4 5MP 12CH Dual-Band Wi-Fi Surveillance System, 12- Channel NVR with 1TB HDD, 4pcs of 5MP Cameras, Inte lligent Detection, 24/7 Recording, IP67 Weatherproof Rating, and More. • 5MP HD with Dual-Band WiFi • Person/Vehicle/Animal Detection •...
- Page 2 Power Requirem ents Power Requirements DC 12.0V 1A, <12W Interface Power Port DC power port Reset Button Ethernet Port One 10M/100Mbps; RJ45 Storage Reolink NVR Built-in microphone Audio In/Out Wi-Fi Wireless Standard IEEE 802.11a/b/g/n Operating Frequency 2.4GHz/5GHz Wireless Security WPA-PSK/WPA2-PSK Software...
- Page 3 Weatherproof IP67 Mechanical Dimensions 。67 x 186mm Weight 415g Wa rr a nt y 2-year limited warranty. Limited Warranty Gallery & Specs 1. Power LED 2. HDD LED 3. USB Port 1. Antenna 2. Reset Button 3. Power Input 4 . USB Port 5.
- Page 4 1. Antenna 2. Bracket 3. Metal-Aluminum Housing 4. IR LEDs 5. High-Resolution Lens 6. Daylight Sensor 1. Turn the adjustment knob counterclockwise to loosen the bracket and adjust the camera in any direction. <br>2. After adjustment, rotate the adjustment knob back to secure and fixthe camera in place.
