GM ACDelco 10335584 Programming Instructions

KEY FOB PROGRAMMING INSTRUCTIONS -
10335584, 10335585
FOR AUTOMOBILES:
• 2001-2005 Chevrolet Venture
• 2001-2005 Pontiac Montana
REQUIRED TOOLS:
• None
IMPORTANT:
ALL TRANSMITTERS WHICH ARE TO BE RECOGNIZED
BY THE REMOTE CONTROL DOOR LOCK TRANSMITTER (RCDLR) MUST BE
PROGRAMMED IN A SINGLE PROGRAMMING SEQUENCE. IF THE SYSTEM
IS PLACED IN PROGRAM MODE IT WILL ERASE ALL PREVIOUSLY PRO-
GRAMMED TRANSMITTERS UPON THE RECEIPT OF THE PROGRAMMING
SIGNAL FROM THE FIRST TRANSMITTER. UP TO FOUR TRANSMITTERS CAN
BE PROGRAMMED. DO NOT OPERATE OR PROGRAM THE TRANSMITTERS IN
THE VICINITY OF OTHER VEHICLES THAT ARE IN THE KEYLESS ENTRY PRO-
GRAM MODE. THIS PREVENTS THE PROGRAMMING OF THE TRANSMITTERS
TO THE INCORRECT VEHICLE.
BEFORE YOU BEGIN:
1. Remove the ignition key from the ignition lock cylinder.
2. Remove the BCM PRGRM fuse from the fuse block. (Refer to your
Owner's Manual for the location of your instrument panel fuse block
and the Fuse Usage Chart Figure 1).
3. Close all of the doors.
PROGRAMMING INSTRUCTIONS:
1. Insert the ignition key into the ignition lock
2. Within 1 second, perform the following actions:
Turn the key to ACC, then to OFF, then to ACC.
3. Open and then close any vehicle door.
NOTE:
A chime will be heard in order to confirm that the programming
mode has been entered.
4. Press and hold the transmitter LOCK and UNLOCK buttons
simultaneously for approximately 14 seconds. Important: After
approximately 3–5 seconds you will hear a chime to confirm
that the programming has been completed for that transmitter.
5. Repeat the previous step in order to program each additional
transmitter.
cylinder.
INSTRUCTION SHEET
(Figure 1)
