Oemtools 27404 Operating Instructions And Parts Manual

Operating Instructions and Parts Manual
Please read and save these instructions. Read through this owner's manual carefully before using product. Protect yourself and others by observing
all safety information, warnings, and cautions. Failure to comply with instructions could result in personal injury and/or damage to product or property.
Please retain instructions for future reference.
FOR CUSTOMER SERVICE
Technical Question?
CALL 1-866-458-2472
customerservice@oem-tools.com
INTENDED USE
This tool set is made for checking and setting the engine timing during replacing the tooth belt / timing chain and replacing the cylinder head
gasket pm VAG 1.9L / 2.0L TDI (Pump-Nozzle), 1.9L TDI (Distributor Injection Pump), 2.5L V6 TDI, 3.3L V8 TDI Diesel engines and 1.2L 3-cylinder
and 1.4L / 1.6L 4-cylinder gasoline engines.
WARNING
This manual servies as a brief guide and does not replace a workshop manual. Always refer to the vehicle-specific service literature,
particularly the technical data such as torque values and instructions for disassembly/assembly, etc.
SAFETY WARNINGS
• Do not use the tool if parts are missing or damaged
• Use the tool for the intended purpose only
• Never place the tool on the vehicle battery due to a risk of a short circuit
• Be careful when working with the engine running, loose clothing, tools and other objects can be caught by rotating parts and cause serious injury
• Keep children and other unauthorized persons away from the work area
• If you remove the ignition key before repairing, you can prevent the engine from being started accidentally and resulting in engine damage
• After repair or before starting the engine, turn a minimum of 2 turns by hand and check the timing again
• Turn the engine only in the normal direction of rotation (clockwise unless otherwise specified)
