Biancheng Electronic Technology WD-01 User Manual

Wireless Intercom Doorbell User Manual
Power On / Off:
Press and hold button for 5 seconds to power on / off the receiver.
Transmitter doesn't need to be powered on.
Calling and Answer:
Press the call button on the transmitter. The receiver will ring and press
Button to answer. It is fully handfree and duplex communication. When the call is
over, press button to hang up. After the call, put the receiver back to the
charging base.
Volume:
Press the VOL- or VOL+ button to change the volume.
Receiver Music:
After the receiver is powered on, press and hold button for
5 seconds to change the music. There are 4 music available.
Pairing:
After the receiver is powered on, press and hold Power button and VOL+ button at
the same time until you hear a beep. Press the call button on the receiver once, and
it will show a blue light. After that, press the call button 6 times very fast. And the
blue light will be off. Now original pairing is canceled. And press and hold VOL- and
VOL+ buttons together for 5 seconds until it says Searching. Press and hold the call
buttons on the transmitters until you hear "Successful". Now the pairing is
done.
When fully charged, the transmitter can be used for 4 months.
When fully charged, the receiver can be used for a week.
Transmitter LED Indicator: The LED indicator light is red when charging and the red
light is off when fully charged. LED indicator is always blue during the call.
Receiver LED Indicator: The LED indicator light is red when charging and the red
light is off when fully charged.
When the receiver is in the standby state, the LED indicator will light up blue every
five seconds.
Manufacturer: Shanghai Biancheng Electronic Technology Co., Ltd.
Address: Building #C, 180 South Changjiang Road, Shanghai, China
TEL: +86 15921788065 Website: www.wirelesslinkx.com
