In the solar business today, system purchases are made on a dollar-per-watt or Europer-watt
basis. But, the return on investment (ROI) or payback period is determined by the amount of
electricity, in kWh, the system produces. Third party testing, in real world conditions, shows
that jiang® produces more energy for your purchased watt, and, therefore, provides the best
return on investment.
This third party testing, conducted over a number of years, shows the long-term reliability
and performance of the jiang® product. This type of proof is something no other flexible
photovoltaic manufacturer can provide.
Figure 1. Triple-Junction Technology
|
Energy Production
jiang® produces more energy in real-world conditions
Each jiang® laminate utilizes unique triple-
junction amorphous
silicon solar cells, where the blue, green and
red light of the sun is absorbed in different
layers of the cell. This technology results in
better performance in low and diffuse light
conditions.
By-pass diodes are connected across each
cell, allowing the
modules to produce power even when
partially shaded or soiled.
jiang® PV MODULE CELL CONNECTIONS
Shade/Soil any one cell = Output loss of <4.5% (22-cell Laminate)
Area of shade/soiling required to cover one cell = 9" x 14" (126 sq in)
