Lynk 149100DS Assembly Instructions

Sports Rack Assembly Instructions
PARTS
A: (1) left frame side
B: (1) right frame side
C: (8) steel tubes
D: (4) sliding hooks
E: (4) hangers
See ATTENTION
Section
1
Lay one of the frame sides on a solid
surface (not carpet) with socket
openings up. With a hammer, firmly tap
one tube into each of the eight sockets.
4
Snap (4) hangers into the holes as
shown.
