- Page 1 Design for Better Life COMPUTER DESK WITH DRAWERS A6 - 100 ASSEMBLY INSTRUCTIONS pamrayservice@gmail.com IMPORTANT Please read this manual carefully before beginning assembly of this product.Keep this manual for future reference.
-
Page 2: Customer Service
COMPUTER DESK WITH DRAWERS A6 - 100 Note and Service Note ！ • It's recommended to have two people for the installation, this will significantly improve your efficiency. • Before assembly, please read this USER MANUAL first,and check according to Parts List to make sure all parts are included. •... -
Page 3: Parts List
COMPUTER DESK WITH DRAWERS A6 - 100 PARTS LIST With 4 round holes Left Leg Frame Short Metal Tube With 4 round holes 2 square holes Drawer Right Leg Frame With 1 large hole 1 small hole L: 36.22 Inch Drawer Bottom Top Metal Tube SIZE: L 38.58 Inch... -
Page 4: Disassembly Diagram
COMPUTER DESK WITH DRAWERS A6 - 100 Disassembly Diagram Design for Better Life... - Page 5 STEP 1 Assembly Instructions The square hole on the right leg should face the left side. The hooks and the desk leg are attached to the top metal tube, so the installation of the hooks can only be completed in this step. The large hole facing downward, positioned near the right side.
- Page 6 STEP 2 Assembly Instructions Thread the bolt through the large hole in the upper section of the top metal tube and attach it to the embedded connector on the support leg. The square hole on the support leg faces the right leg.
- Page 7 STEP 3 Assembly Instructions Design for Better Life...
- Page 8 STEP 4 Assembly Instructions Design for Better Life...
- Page 9 STEP 5 Assembly Instructions Design for Better Life...
- Page 10 STEP 6 Assembly Instructions Long Hex key Short Hex key Design for Better Life...
- Page 11 STEP 7 Assembly Instructions Pay attention to the orientation of the slide track, with the curved opening facing forward and the slide track stopper at the rear. If it sinks in,pry it up Design for Better Life...
- Page 12 STEP 8 Assembly Instructions Design for Better Life...
- Page 13 STEP 9 Assembly Instructions Design for Better Life...
- Page 14 STEP 10 Assembly Instructions Short Hex key Do not over-tighten, as it may cause damage to the components. Design for Better Life...
- Page 15 STEP 11 Assembly Instructions Design for Better Life...
- Page 16 Design for Better Life pamrayservice @gmail.com...
