Superb CHR Installation And Owner's Manual

Empire comfort systems outdoor gas fireplace installation instructions and owner's manual

Advertisement

Quick Links

WARNING: If the information in this manual
is not followed exactly, a fire or explosion may
result causing property damage, personal in-
jury or loss of life.
— Do not store or use gasoline or other flam-
mable vapors and liquids in the vicinity of
this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
Do not try to light any appliance.
Do not touch any electrical switch; do
not use any phone in your building.
Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
If you cannot reach your gas supplier,
call the fire department.
— Installation and service must be performed
by a qualified installer, service agency or the
gas supplier.
WARNING: For Outdoor Use Only.
WARNING: Improper installation, adjustment,
alteration, service or maintenance can cause
injury or property damage. Read the installa-
tion, operating and maintenance instructions
thoroughly before installing or servicing this
equipment.
CHG/CHR
R-5914

INSTALLATION INSTRUCTIONS

OWNER'S MANUAL
Chimenéa
AND
OUTDOOR GAS FIREPLACE
MODELS
CHR-2
CHG-2
EFFECTIVE DATE
JUNE, 2001
AVERTISSEMENT: Si les informations dans ce
manuel ne sont pas exactement suivies, un feu ou
une explosion peut en résulter causant des
dommages à la propriété, des blessures corporelles
ou la mort.
— Ne pas entreposer ou employer de la gazoline ou
d'autres vapeurs ou liquides inflammables à
proximité de cet appareil ou tout autre appareil.
— Que faire si vous sentez le gaz.
N'essayer pas d'allumer un appareil.
Ne toucher pas un interrupteur élec-trique;
n'employer pas un téléphone dans le bâtiment.
Appeler immédiatement votre fournis-seur de
gaz en employant le téléphone de votre voisin.
Suivre les instructions du fournisseur de gaz.
Si vous ne pouvez pas contacter votre
fournisseur de gaz, appeller le poste de
pompiers.
— L'installation et le service doivent être exécutés par
un installateur qualifié, une agence d'entretien ou
un fournisseur de gaz.
AVERTISSEMENT: Pour Utilisation à l'Extérieur
Seulement.
AVERTISSEMENT: Si l'installation, l'ajustement,
l'altération, le service ou l'entretien est incorrectement
fait, des dommages à la propriété ou des blessures
peuvent s'en suivre. Lire complètement les instructions
pour l'installation, le fonctionnement et l'entretien
avant d'installer ou de réparer cet équipement.
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CHR and is the answer not in the manual?

Questions and answers

Summary of Contents for Superb CHR

  • Page 1: Installation Instructions

    WARNING: Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Read the installa- tion, operating and maintenance instructions thoroughly before installing or servicing this equipment. CHG/CHR R-5914 INSTALLATION INSTRUCTIONS OWNER'S MANUAL OUTDOOR GAS FIREPLACE Chimenéa AVERTISSEMENT: Si les informations dans ce manuel ne sont pas exactement suivies, un feu ou une explosion peut en résulter causant des...
  • Page 2: Table Of Contents

    • Faire une inspection visuelle de la flamme du brûleur. Nettoyer et remplacer les pièces défectueuses. Ne pas entreposer ni utiliser de l'essence ni d'autres vapeurs ou liquides inflammables dans le voisinage de l'appareil, ni de tout autre appareil. Page AVERTISSEMENT CHG/CHR...
  • Page 3: Specifications

    The pressure regulator and hose assembly supplied with the out- door gas fireplace must be used. A replacement pressure regulator and hose assembly for this outdoor gas fireplace can be obtained by contacting Empire Comfort Systems, Inc. CHR and CHG Natural Gas...
  • Page 4 American National Standard (National Fuel Gas Code) known as NFPA 54 and ANSI Z223.1 or CAN/CGA-B149.1 NATURAL GAS INSTALLATION CODE or CAN/CGA-B149.2 PROPANE INSTALLATION CODE. *Available from the American National Standards Institute, Inc., 11 West 42nd St., New York, NY 10036. CHG/CHR...
  • Page 5: Clearances

    Figure 2 Figure 3 CHG/CHR CLEARANCES Minimum Clearances From Combustible Construction (Figures 2 and 3) Side 6" Rear 6" 47" from top of unit or 96" from floor Floor Combustible Minimum Clearances From Combustible Construction with 20 lb. Propane (LP) Tank Attached to Outdoor Gas Fireplace...
  • Page 6: Set-Up Instructions

    9. The installation sequence is to interlock the flicker shield halves first to prebend the tabs. Place the left half under the outdoor gas fireplace with the cut-out around the pipe. Interlock the right half with the left half. Figure 6 Figure 7 CHG/CHR...
  • Page 7 (#2) log. Recesses, tabs and holes are provided to locate the logs properly. See Figure 10 for proper placement. Installation of logs is completed. CHG/CHR Figure 10 Refer to the following warning. Warning: Failure to position the parts in accordance with...
  • Page 8: Gas Conversion Instructions

    20. You are now ready to light your outdoor gas fireplace. See the lighting instructions before proceeding. WARNING: Failure to read and follow those instructions may result in a fire or explosion causing property damage, personal injury or loss of life. GAS CONVERSION INSTRUCTIONS CHG/CHR...
  • Page 9: Leak Testing

    (1) minute after the burner is lit. Release knob, and it will pop back up. Burner should remain lit. If it goes out, repeat steps 1 through 4. CHG/CHR LEAK TESTING 5. After the installation of all gas-related items: i.e. hose, regulator, LP gas cylinder, natural gas hose or natural gas regulator;...
  • Page 10: Maintenance And Service

    The burner must be replaced prior to the outdoor gas fireplace being put into operation if it is evident that the burner is damaged. A replacement burner for this outdoor gas fireplace can be obtained by contacting Empire Comfort Systems, Inc. Page 10 Flashback from Spiders (Figure 14) In some areas of the country, spiders or small insects have been found to create "flashback"...
  • Page 11: Trouble-Shooting

    R-5909 CAST BURNER ASSEMBLY WITH PIPE AND VENTURI R-5638 VALVE COVER CHG/CHR TROUBLE-SHOOTING Is there an adequate gas supply? Does the orifice or burner need cleaning? Is the air shutter too far open or closed? Is the gas supply, or gas pressure low? The smell of gas with flames appearing sooty yellow.
  • Page 12: Parts View

    Do not order bolts, screws, washers or nuts. They are standard hardware items and can be purchased at any local hardware store. Order parts through your local dealer. Shipments contingent upon strikes, fires, and all causes beyond our control. Empire Comfort Systems, Inc. Nine Eighteen Freeburg Ave. Belleville, Illinois 62222-0529 Page 12 Part Description...
