Summarization of Contents
Introduction and Controls
Bronze Series Guitar Controls
Details the three controls for Bronze Series guitars: Master Volume, 3-way Pickup Selector, and Master Tone.
Multi-Series Guitar Controls
Explains the four controls for Platinum, Platinum Pro, Acrylic, NJ, and Classic Series guitars.
Exclusive Series Guitar Setup
Describes the traditional control layout for Exclusive Series guitars with two pickups.
Platinum Series Bass Controls
Outlines the controls for Platinum Series basses with split-coil pickups.
NJ and Innovator Series Bass Controls
Details controls for NJ and Innovator Series basses with active EQ systems.
SpeedLoader Tremolo Fine Tuner Range Adjustment
Reset Fine Tuner Range Step 1
Position all fine tuner screws to the middle of their movement range.
Reset Fine Tuner Range Step 2
Adjust specific fine tuners to establish a reference point.
Reset Fine Tuner Range Step 3
Align remaining fine tuner screws to match the reference point.
Reset Fine Tuner Range Step 4
Prepare for tuning by ensuring all fine tuners are centered.
Reset Fine Tuner Range Step 5
Begin tuning the guitar using the range tuner set screw.
Guitar Care and Bridge Adjustments
Climate and Humidity Effects
Explains how humidity and temperature extremes can damage guitars.
Instrument Cleaning Procedures
Provides guidelines for cleaning and maintaining guitar finish and parts.
Bridge Height Adjustment
Details how to adjust bridge height for Bronze, Platinum, and other series guitars.
Changing Strings with Floyd Rose
Step-by-step guide for changing strings on guitars with a locking tremolo system.
Intonation and Neck Adjustments
Setting Intonation for Flat Notes
Adjusts saddle position when the fretted note is flatter than the open note.
Setting Intonation for Sharp Notes
Adjusts saddle position when the fretted note is sharper than the open note.
Neck Curvature Adjustment
Explains neck adjustments, advising professional service for truss rod adjustments.
SpeedLoader String Removal Process
Step 1: Push Down Saddle
Initiate string removal by pushing down the back of the saddle.
Step 2: Release Sliding Latch
Pull back the sliding latch to release the string.
Step 3: Release Saddle
Release the saddle to allow it to rotate forward.
Step 4: Tighten Spring Screws
Tighten spring claw screws to pull the spring block tightly against the setscrew.
Step 5: Add Extra Spring
Alternative method to pull spring block using an additional spring.
SpeedLoader Tremolo Bridge Setup
Step 1: Remove Spring Cover
Remove the spring cover plate from the back of the guitar.
Step 2: Locate Tremolo Stop
Find the tremolo stop inside the spring cavity.
Step 4: Remove Bullet from Saddle
Remove the bullet end from the saddle of the string.
Step 5: Pivot Saddle Forward
Manually pivot the saddle forward if there is no string tension.
Step 6: Safety Catch Check
Ensure the sliding latch and safety catch align properly to prevent accidental release.
SpeedLoader String Loading Process
Step 1: Insert Bullet into Nut
Slide one bullet into the nut and the other into the saddle.
Step 2: Engage Sliding Latch
Ensure the sliding latch snaps into place for secure string holding.
Step 3: Seat New String
Press down firmly on the new string to seat it.
Step 4: Stretch String
Perform stretching pulls on the string to set it.
Step 5: Play and Retune
Play the string and use fine-tuners for final pitch adjustments.
