Crest Audio HD12 Specifications page 2

8Ω Stereo Power
4Ω Stereo Power
2Ω Stereo Power
8Ω Bridged Mono Power
4Ω Bridged Mono Power
Max RMS Output Voltage
(each channel)
Peak Output Voltage
(each channel)
Frequency Response
(+0 / -0.3dB, 1W/8Ω)
Power Bandwidth
(rated power at 4Ω, 1% THD+N)
TourClass
THD+N
(rated power at 4Ω, 1kHz)
SMPTE IMD
(rated power at 8Ω, 60Hz & 7kHz)
Damping Factor
(10-400Hz at 8Ω)
Input CMRR
Input Sensitivity
(rated power at 8Ω )
Voltage Gain
Input Impedance (balanced/unbalanced)
Hum and Noise
("A" weighted, full power, 4Ω)
Crosstalk
("A" weighted, full power, 4Ω)
Input Connectors
Output Connectors
Filter Storage
Power Supply
(factory configured)
Idle Current Draw 120V
1/8 Power Curr. Draw
(typical music, 120V/4Ω)
1/3 Power Curr. Draw
(continuous music, 120V/4Ω)
Max Curr. Draw
(circuit breaker rating, 120V/4Ω)
Thermal Emissions
(1/8 Power, 4Ω)
Thermal Emissions
(1/3 Power, 4Ω)
LED Indicators
Construction
Dimensions
(Height x Width x Depth)
Gross Weight, Net Weight
Dealer-Configurable Gain/Sensitivity Options
Rear View
v. 1.1 5/21/97 C3400005
H D 1 2 P OW E R A M P L I F I E R
S P E C I F I C AT I O N S
1kHz, 0.01% THD+N
700W
1200W
1400W
2400W
2800W
90V
126V
20Hz-20kHz, -3dB@135kHz
20Hz-20kHz, -.23dB/+.85dB
® Protection ACL, IGM, AutoRamp, short circuit, DC voltage,
turn-on/off transient, current inrush, sub/ultrasonic input.
<0.01%
<0.01%
800:1
> - 60dB
(1kHz)
0.775V standard (see table below)
X97.5 standard (see table below)
>20kΩ/>10kΩ
-105dB
> - 60dB
Class
H
Female XLR (pin 2+, dealer configurable for pin 3+), TRS (tip+)
(per channel)
5-way output binding posts or Speakon connectors
(per channel)
140,000 F
100V-240V, 50-60Hz
2.8A
10.5A
23.0A
30A
4750 BTU/hr
6300 BTU/hr
Cooling Back-to-front via 2 rear panel mounted variable-speed DC fans
(filters removable without tools)
Controls Front Panel: 2 attenuators
Rear Panel: signal ground lift switch, mode select switch
Clip/Limit, Signal, Temp/DC, Active
(per channel)
Steel chassis, 16 gauge. Double thickness in rack ear areas.
5.25" x 19" x 18" / 133 x 483 x 457mm
72 lbs. (32.68 kg.), 67 lbs. (30.42 kg.)
Warranty 3 years, parts & labor
Factory Standard
Option 1
Option 2
A
+
+
+
B
Power figures are watts per channel, both channels driven.
Crest Audio reserves the right to make improvements in manufacturing or
design which may affect specification. Crest Audio specification literature
is available in electronic form to qualified users. Contact Crest Audio Inc.
for more information. © 1997 Crest Audio Inc.
20Hz-20kHz, 0.1% THD+N
650W
1100W
1100W
2200W
2200W
(market dependent)
Gain Sens
X97.5 .775V
X40 1.87V
X20 3.74V
Designed & manufactured in the USA by:
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
AVIS : RISQUE DE CHOC ÉLECTRIQUE—NE PAS OUVRIR
WARNING TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK DO NOT
EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE.
ATTENTION! POUR ÉVITER LE RISQUE D'INCENDIE OU DE CHOC
ÉLECTRIQUE, NE PLACEZ PAS CET APPAREIL SOUS LA PLUIE OU Á
L'HUMIDITÉ
Crest Audio Inc.
100 Eisenhower Dr.
Paramus, New Jersey 07652 USA
A
A
• •
A B
A
A
+
B
A B
• •
A B B
A B
B
Architect's & Engineer's Specifications
The power amplifier shall have two channels. At 8 ohms, 20Hz -
20kHz, 0.1% THD+N, it shall deliver a minimum of 650 watts per
channel. At 4 ohms, 20Hz - 20kHz, 0.1% THD+N, it shall deliver a
minimum of 1100 watts per channel. In bridged mono mode with an
8 ohm load, 20Hz - 20kHz, 0.1% THD+N, it shall deliver a mini-
mum of 2200 watts.
The amplifier shall have circuitry to protect itself from output short
circuits, thermal overload or other adverse load conditions. The
amplifier shall protect speaker loads from DC voltage on outputs.
The amplifier shall have active clip limiting and impedance sensing
circuitry. Output relays shall protect the speakers from amplifier
failure.
Two rear panel mounted variable speed DC fans (filters detachable
without tools) shall provide back to front air flow through the chas-
sis.
Each channel shall have a standard (factory-set) input sensitivity of
0.775 Volts, and shall be fitted with an internal jumper which
allows the gain to be altered to X20 or X40. The hum and noise
level shall be 105 dB below rated output, "A" weighted.
IMD shall be less than 0.01% at rated power, 60Hz and
7kHz.
The amplifier shall have a class H output stage. The fre-
quency response shall be 20Hz-20kHz, +0, -0.3dB at rated power.
The amplifier will operate at 100V-240V, 50-60 Hz AC (configured
at factory). Maximum current draw shall not exceed 30 amperes at
120VAC (limited by front panel breaker for bench tests).
Front panel indicators shall include Active, Protect, Signal, and
Clip LED's for each channel. Front panel attenuators shall be
recessed and detented.
Rear panel input connectors shall be female TRS and XLR type,
internally dealer-configurable for pin 2 (factory setting) or pin 3
positive. Output connectors shall be 5-way output binding posts. A
ground lift switch and a Stereo/Parallel/Bridged Mono mode oper-
ation switch shall be provided.
A rear-panel IEC AC mains socket (with power cord) or single AC
mains cord having an appropriate AC plug for the intended operat-
ing voltage shall be provided (market dependant).
The packaging of the amplifier shall allow for standard rack
mounting without requiring space between similar units. Optional
rack mount handles will be available. Dimensions shall be 19"
(483mm) wide, 5.25" (133mm) high and 18" (457mm) deep. The
amplifier shall weigh 67 lbs. (30.42 kg.) net, and shall be designat-
ed the Crest Audio model HD12 .
2+
1
3 -
100 Eisenhower Dr., Paramus NJ 07652 USA
: 201.909.8700
TEL
SMPTE
Crest Audio Inc.
: 201.909.8744
FAX
http://www.crestaudio.com
Printed in USA
