American Trails Freedom 605-1X Assembly Instruction

Assembly Instruction
Item# 605-1X
Freedom Nightstand/End Table
with USB Port
Hardware
USB Port
USB Adapter Specifications
Input Voltage
Input Current
Output Voltage
Load Regulation
Output Current
Output Ripple
Efficiency
Output Plug
Over Power
Short Protection
Attach supplied AC cable from underneath
the table and plug into a standard wall
outlet. Unit is now ready to accept the
supplied 3-in-1 cable.
*After multiple devices are charged simultaneously,
please disconnect them in the reverse order.
USB 1 & 2 PORTS
Fast charging ports for devices that
require higher current, ideal for iPads
and Android tablets, while also
compatible with other mobile devices.
USB 3 & 4 PORTS
Standard USB ports, ideal for
smartphones and other mobile devices.
AC 100-240V 50/60Hz
≤ 350mA @ 220V AC w/ full load
5.0V ± 0.25V
-0.5% (Max)
3.1A Max
< 400mV p-p
> 75% @ 220V AC
USB Type A x 4
≈ 17W @ 220V AC
Auto Recovery
