Summary of Contents for IOOIOO TC156Y
- Page 1 TC156Y Portable Monitor User Manual...
-
Page 3: Safety Information
Safety Information Before setting up this device, carefully read all documentation included in the product packag- ing. This equipment has been designed with personal considerations in mind, but improper use may result in electric shock and fire. In order not to damage the safety components inside the monitor, please observe the following regulations during installation, use and maintenance. - Page 4 To avoid personal injury, observe the following: •Do not place the monitor on a sloping surface unless there are safety measures. • Do not drop, click or throw objects/toys on the screen. Personal injury, product damage, and screen damage can result. To avoid personal injury, observe the following: •...
- Page 5 Do not rub the screen panel with hard objects, as this will scratch or permanently damage the LCD. Do not press the LCD screen with your fingers for a long time, otherwise it will produce afterglow, which will damage the screen in severe cases.
-
Page 6: Monitor Introduction
Monitor Introduction 15.6‘’ Hand thumbwheel Power/Return 3.5MM USB TypeC Headphone Plug Full-featured Interface mini HDMI USB TypeC Power Supply Interface -04-... -
Page 7: Button Introduction
Button Introduction • The function keys are designed with a thumb wheel, and an independent Power/Return key . • Press and hold the Power/Return for 3 seconds to turn on/off the monitor. • Press thumb wheel to open the OSD menu of the monitor, in the menu, turn the thumb wheel up and down to control the cursor, press the thumb wheel to confirm, short press the Power/Return to return •... - Page 8 Device Connection Reference 1.Connect Computer with Full-featured Interface Transmission of Video, Audio, Touch Signal, Power Supply The monitor supports a full-featured USB3.1TypeC interface connected to the standard wire and one line for extended display or copy display use. The touch version of ZB156 can be used for touch operation on the monitor (system support is required, some systems are better optimized for touch, enter Windows 10, please consult the dealer for details)
- Page 9 *When the external power supply is used, the monitor charges the mobile phone reversely through the external power supply (in order to ensure the monitor and mobile phone If you can get enough working current, please use a charger or power bank with at least 18W as the external power supply, and a higher power charger can quickly charge the mobile phone.
- Page 10 The monitor has a Mini HDMI interface, which is compatible with most HDMI devices, when connecting to a computer with an HDMI interface,you need to connect HDMI to the computer, support computer USB3.0 power supply and external 5V2A power supply. ( The touch screen version of the model must connect the TypeC to the USB interface the computer to realize , and the user can provide the USB A to C cable by himself) 5.
-
Page 11: Common Problems And Solutions
Common Problems And Solutions Q: The monitor does not light up, and the power indicator light does not light up A: Press the power button to check whether the monitor is turned on; check whether the USB cable is properly connected to the monitor and the power supply interface. Q: The display is off, and the power indicator is red A: Check whether the monitor and the connected device are turned on;... -
Page 12: Maintenance And Cleaning
Maintenance and Cleaning Cleaning • Power off the monitor and unplug the power cord. Use a lint-free, non-abrasive cloth to clean the display surface. Moisten a cloth in a mild detergent to remove stubborn stains. • Do not use cleaners containing alcohol or acetone. Use a special cleaner for liquid crystals. -
Page 13: After-Sales Service
After-sales service This product provides Gobigger original one-year warranty service • Within 7 days from the date of sale of the product, consumers can choose to return, exchange or repair if there is a failure listed in the "Microcomputer Product Performance Failure Table". - Page 14 •Damage caused by accidental factors or human behavior and external force (including operation error, handling, bumping, input of inappropriate voltage, etc.). • using non-standard or unpublished software or non-standard related computer components (such as: graphics card, etc.). • Damage caused by force majeure such as natural disasters (such as earthquakes, fires, floods, etc.).
