Melnor 9538 Manual

Note:
Pulsating sprinklers
require a minimum
of 30 psi. Without
adequate pressure,
the head will not
rotate properly.
Metal Pulsating Sprinkler Adjustements
Adjusting the deflector shield
■
the distance the water sprays . Raise the
deflector shield up to get the maximum
distance. Lower the deflector shield into the
spray of the water and the distance of the
spray will be reduced.
The adjustment screw
■
the sprinkler head diffuses the water as
it is sprayed. When the screw is in the out
position, the water sprays in a fine stream.
When the screw is in, the tip of the screw
enters the stream of the water; this disrupts
the spray and causes the sprinkler to create a
more gentle, shower-like pattern.
Flip clip
■
sprinkler to rotate 360°.
When the clip is in the down position, the
■
Spray Distance
head will rotate between the two rings
Adjusting the rings will limit how much of a
circular area is watered.
To connect multiple units, use
■
second hose and an additional sprinkler unit.
Additional units will diminsh the maximum
coverage area of all sprinklers. (not available
Water Diffusion
on all models)
Flip Up For Full
Circle
360°
Coverage Angle
Multiple Unit
Attachment
at the front of
to the up position to allow the
Spray Angle Options and Adjustments
90°
180°
270°
