HammockSource Large Tri-Beam Hammock Stand Manual

Large Tri-Beam
Congratulations on your purchase of the Large Tri-Beam
We believe that you will find it a product of unsurpassed quality and
durability
Hardware Included:
3 - Poles
2 - Foot Brackets
2 - Pole End Caps
4 - Foot End Caps
2 - "S" Hooks
Assembly:
1. Place the foot end caps on the foot brackets.
See Fig. 1 for proper cap selection.
2. Place one pole between the two foot brackets and
insert the foot brackets. Push down on the spring pins
while pushing the poles into place until the spring pins on
the foot brackets exit through the holes and lock into
place. See Fig 2.
3. Arrange the remaining two poles at each end. Push down
on the spring pins while pushing the poles into place until the
spring pins on the foot brackets exit through the holes and
lock into place.
4. Place the pole end caps (w/holes) on the end poles
aligning the holes prior to pressing them down on the pole.
5. Insert the "S" hooks at each end cap. This is done by
inserting the hook perpendicular to the pole and turning it to
align with the pole.
6. Using the chain provided with your hammock, hang your
hammock tightly on the "S" hooks and sit into the hammock
slowly. Your hammock will stretch and you may experience
"bottoming-out" initially. Take extreme care when sitting in
the hammock for the first time. Once this initial stretching
occurs, you will want to tighten the hammock chains. Repeat
this until a comfortable height is reached; always using care
when sitting in an untightened hammock.
WARNING: DO NOT EXCEED LOAD LIMIT OF 600 LBS.
CAUTION!! CAUTION!!
Stands should be examined periodically to ensure that:
- Each welded joint is fully intact.
- There are no missing caps (rust protection).
- There is no excessive rust.
Hammock Stand
®
End Caps
Pole
Foot
Fig. 1
If you have any questions regarding our products, call our
toll-free consumer customer service line:
Visit our web page: www.thehammocksource.com
®
Hammock Stand.
Fig. 2
CAUTION!
• Do not drag or pull your hammock stand when
moving or adjusting.
• ALWAYS lift from both ends.
• If a wheel kit, purchased separately, is in-
stalled, you may lift and move from the opposite
end from the wheels.
• NEVER drag or pull your hammock stand even
when wheels are installed.
• After any moving or adjusting of your ham-
mock stand, ALWAYS inspect to make sure the
spring pins are properly inserted. Failure to do
so may result in the hammock stand collapsing
upon use.
Products of The HammockSource are guaranteed to be
free of defects in workmanship and materials. If this unit
is found, within its first 90 days, to be defective, it will be
replaced without charge upon the return of the unit. A
Return Authorization is needed for return.
If you have any questions about your new Large Tri-
Beam ® Hammock Stand please contact us at:
The HammockSource - Post Office Box 1602, Greenville,
5059-SP(b) North Carolina 27834 Consumer Customer Service:
A01 800.643.3522
800.643.3522
Spring Pins
CAUTION!
