Airdog 192556000303 Manual

Components
Silicone Tubing
Wearable Seat
Operation
Battery Life
NOTE:
1. Recharge it in time when power is low to avoid battery failure.
2. The data were measured at 25°C and 25%RH; The endurance is different
under different temperature and humidity conditions.
Specification
Model: JHB-18 Input Power: 4.2W
*
Input Voltage: 5V Purification Efficiency: 97.8%
*
DO NOT use 9v plug.
Mask
USB Charging Port
(*Keep open)
Clean Air Vent
ON
Short press to open.
(Default: low wind speed)
Fan Speed Switch
Short press POWER button to adjust.
Three speeds: Low, Mid, High.
OFF
Long press to shut down.
Standard
Green
4h
High battery level
Yellow
3h
Mid battery level
Red
2h
Low battery level
Installation
1
Power
E-ball
2
Filter-ball
Shutter 3
Filter Change
Yellow light blinks: need to change the filter.
1
2
Booster
8h
3
5h
0.5h
4
Follow and like us on facebook
E-mail : Support@AirdogUSA.com
Install the E-ball and the Filter-ball on
the Wearable Seat separately.
Install the air outlet of the soft tube at
the connector.
Install the air inlet at the mask and
connect with the soft tube.
Open the cap of the cleaning module
by rotating counterclockwise.
Take out the dirty filter and put in a
new one. (Be careful touching the
filter with contaminant. Gloves are
recommended.)
Close the cap by rotating clockwise.
Cleaning reset:
Long press power button for 5
seconds until unit is on.
Scan QR code for more Video Instructions
(Airdog Youtube channels)
