Summary of Contents for abetap 06975361070242
- Page 1 Bird Feeder Cam Quick Guide FCC ID: �AXEK-N��� Model: N���...
-
Page 2: Table Of Contents
Catalog 1. What's In The Box P. 1 2. Camera Structure P. 2-3 3. Insert Micro SD Card P. 4 4. Assemble Bird Feeder Cam P. 5 5. Battery Charging P. 5 6. How To Turn On & Off The Camera P. -
Page 3: What's In The Box
What's In The Box Mounting Screws Anchors Black Strap Roof Bird Feeder Cam Perch Screw Perch Hose Clip Ejector Pin Mounting Bracket Type C Power Cable Quick Guide... -
Page 4: Camera Structure
Camera Structure Bird Seed Reservoir PIR Infrared Microphone Status Light Spot Light Lens LED Infrared Perch... - Page 5 Micro SD Card Slot Power Button Reset Button Antenna Speaker Camera Direction Adjuster...
-
Page 6: Insert Micro Sd Card
Insert Micro SD Card Bird Cam comes with a built-in card slot which supports up to 128GB Micro SD card. Step 1: Rotate the camera down to the bottom. Step 2: Open the top silicone plug. Insert the Micro SD card. Make sure to plug it in the right direction. -
Page 7: Assemble Bird Feeder Cam
Bird Feeder Cam Assemble Assemble Perch Use the provided perch screw to install the perch. Battery Charging The batteries inside the camera are not fully charged according to the transportation safety regulations. Please fully charge the camera before using it. Please charge the batteries with provided Type C Port Cable (DC5V/1.5A adapter not included).d The status light will be in solid yellow when charging, and will turn to solid green when it is fully charged. -
Page 8: How To Turn On & Off The Camera
How To Turn On & Off The Camera To turn on the camera: Long press the power button for 3s to turn on the camera. Then the Status Light in the front of the camera will be solid blue. Double click the power button to enter WiFi mode after the prompt tone. -
Page 9: Read Before Installation
Read Before Installation 1. Keep Bird Feeder Cam and all accessories out of reach of children and pets.d 2. Make sure the camera has been fully charged (DC5V/1.5A). 3. Working temperature: -10°C to 50°C (14°F to 122°F) Working relative humidity: 0-95% 4. - Page 10 mode after the prompt tone.
- Page 11 When connecting the camera for the f irst time, use the App and...
-
Page 14: Installation
Installation Check the following things before you drill holes on your wall: Bird Feeder Cam has been successfully added to your VicoHome App and is able to stream video. Wall Installation: Step 1: 1. Use the provided drilling template to mark the position of holes on your wall. Use drill bit(5/16,8mm) to drill two holes. - Page 15 Step 2: Slide the Bird Feeder Cam into the bracket through the slide rail. Tree Installation: Step 1: Wrap the Mounting Bracket around the tree with the Black Strap.
- Page 16 Step 2: Slide the Bird Feeder Cam into the mounting bracket. Stand Installation: Step 1: The Bird Feeder Cam can be placed steadily on a flat surface, but for stability, we recommend that the backplane is installed and fixed on a flat surface. Use the provided drilling template to mark the position of holes on flat surface.
- Page 17 Step 2: Install the anchors to fix the screws. (Install on wood skip this step.) Step 3: Install the Mounting Bracket on flat surface with the screws provided. Step 4: Slide the Bird Feeder Cam into the mounting bracket.
- Page 18 Pole Installation - Hose clip Hose Clip Step 1: Attach Bird Feeder Cam to the pole with the Hose Clip turning the handle clockwise. Step 2: Slide the Bird Feeder Cam into the bracket through the slide rail.
-
Page 19: Installation Of Solar Panels
Installation Of Solar Panels Solar panel Step 3: Screw the bracket to the wall, then rotate the solar panel so the 1/4" nut on the back fits with the 1/4" screw on the bracket. Step 4: Open the back cover, pass the solar panel cable through the rear, connect it to the camera at the front of the device, and then close the back cover... -
Page 20: Cleaning Bird Feeder Cam
Cleaning Bird Feeder Cam Step 1: Unplug the charging cable and put on the silicone cover. Step 2: Using the Pull Tab on the base of the feeder, remove the Bird Feeder Cam from the bracket. Step 3: Open up the buckle on the back of the Bird Feeder Cam, and pull up on the roof to open. - Page 21 Step 4: Pour water into the top of the seed reservoir. Do not wash the camera or any of its components. They are water resistant, not water-proof. Dry the feeder, including the seed reservoir. Step 5: Re-attach the Roof: Push the roof down and engage the snaps on the back of the Bird Feeder Cam.
- Page 22 Step 6: Re-attach the bracket to the Bird Feeder Cam base. Adjust the angle for both the Bird Feeder Cam and camera. Step 7: Open the silicone plug, re-plug in the Solar Lite.
-
Page 23: How To Add Bird Seed
How to Add Bird Seed Buckle Step 1: Open up the buckle on the back of the Bird Feeder Cam, and pull up on the roof to open. Step 2: You can add bird seed. Finally, close the roof back. -
Page 24: Status Light
Status Light This camera uses status light to communicate. Description LED Indicator Solid Blue Working Sleep/Power Off None Charging Solid Yellow Solid Green Charging Finished Al Bird Recognition * Al version: The service is free for life. * Lite version: This service requires a subscription. Al Bird Recognition has undergone massive machine learning and uses Al intelligent recognition algorithms to inform you in real time "what species of bird are coming", automatically save the bird images/videos data for you, and also provide bird... -
Page 25: Warning
Warning NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. - Page 26 Economic Development Canada's licence-exempt RSS(s). Operation is subject to the following two conditions: This device may not cause interference. This device must accept any interference, including interference that may cause undesired operation of the device. Pour maintenir la conformité avec les directives d' exposition RF de la FCC, cet équipement doit être nstallé...
