Online LED Store LAMPHUS SolarBlast SBTA84 Manual

www.online-led-store.com
Phone: 1-855-LED-ONLINE (1-855-533-6654)
Fax: (909) 575-6722
E-mail: support@online-led-store.com
IMPORTANT: READ CAREFULLY BEFORE ASSEMBLY AND USE.
• Installer of this product must have a good understanding of automotive electronics, systems,
and procedures.
• In the case that holes must be drilled in order to properly mount the product, the installer must
examine both sides of the mounting surface before drilling begins. It is the installer's
responsibility to be sure that no vehicle components or vital parts could be damaged by the
drilling process. De-burr any holes in order to remove metal shards and remnants. Use
grommets in all wire passage holes.
• If this manual states that this product may be mounted with suction cups, magnets, tape, or
Velcro®, clean the mounting surface and dry thoroughly prior to applying any adhesives for
maximum adhesion.
Do not attempt to activate or operate this product under hazardous driving situations.
•
Mounting
CAUTION! Permanent mounting of this product will require drilling. It is
absolutely necessary to make sure that no other vehicle components could be
damaged by this process. Check both sides of the mounting surface before
starting. If damage is likely, select a different mounting location.
WARNING! If a Quick Direction Controller is to be used, make sure the LED
strobe light unit is mounted in a way that the directional signals goes the same
way as the directional buttons on the controller. The mounting bracket may
need to be repositioned based on mounting location and direction which the
LED strobe light will be facing.
1. Place the mounting brackets against the mounting surface.
2. Mark the area where the mounting holes are to be drilled. Confirm that no vehicle parts
could be damaged by the drilling process.
3. Using a drill bit of appropriate size, drill two mounting holes. Thoroughly de-burr all hole(s).
4. Secure the mounting bracket by using the mounting screws and washers provided.
5. Secure the strobe light unit onto the mounting brackets by using the accessories provided.
Wiring
WARNING! All customer supplied wires that connect to the positive terminal
of the battery must be sized to supply at least 125% of the maximum operating
current and FUSED at the battery to carry that load. DO NOT USE CIRCUIT
BREAKERS WITH THIS PRODUCT!
RED – To 12/24V Power Source
BLACK – To Chassis Ground
YELLOW – Pattern Selection
Apply YELLOW to BLACK for a brief second will advance strobe light unit to the next
-
strobe pattern.
LAMPHUS
36" Super High Intensity LED Traffic Advisor Lightbar
SKU: PSZLEDSTB0458 Rev.1
Deployment area of the vehicle air bags must be cleared. Do not install this product or route
•
any electrical wires near the air bags deployment areas. Refer to your vehicle owner's manual
for the air bag deployment area. Products or wires mounted in the air bag deployment area
will damage, reduce the effectiveness of the air bag, or even act as a projectile which may
cause serious injury or death. The user/installer of this product assumes full responsibility in
determining the proper mounting location while prioritizing the safety of all passengers in the
vehicle.
• This product contains strobe light(s), halogen light(s), high-intensity LEDs, or a combination of
these components. Do not look directly into the lights. Momentary blindness and/or injury to
the eyes could result.
Flash Patterns:
1. Directional Right
2. Directional Left
3. Center Out
4. Center In
5. Double Flash Center
Out
6. Double Flash
Alternating 2 Group
1-2-7-8/3-4-5-6
7. Double Flash
Alternating 2 Group
w/ Single Flash
8. Double Flash
Alternating 2 Group
1-2-3-4/5-6-7-8
9. Triple Flash
Alternating 2 Group
1-3-5-7/2-4-6-8
10. Double Flash
Sequential 4 Group
1-5/2-6/3-7/4-8
Legend:
Combo – Combination
Group:
-
-
Specifications
Input Voltage: 12VDC +/- 20%
Input Current: 0.10 – 1.5 AMPS
Output Power: 5 – 20 WATTS
Online LED Store S2B Inc. ©2016 All Rights Reserved
® SolarBlast
11. Double Flash
Sequential 4 Group
Reverse
4-8/3-7/2-6/1-5
12. Double Flash
Alternating 2 Group
w/ Pulse
1-2-3-4/5-6-7-8
13. Center In and Out
14. Single Flash
Alternating 2 Group
1-2-3-4/5-6-7-8
15. Center Out
Simultaneous Flash
Combo
16. Double Burst
Alternating 2 Group
1-2-3-4/5-6-7-8
17. Hyper Single
Alternating Flash 2
Group
1-2-3-4/5-6-7-8
2 Group: light block flashes alternating between 2 groups. If written as 1-2-3-4/5-6-
7-8, light blocks are separated into 2 groups with group #1 being light blocks #1 – 4,
and group #2 being light blocks #5-8.
4 Group: light block flashes sequentially from group #1 to group #4. If written as 1-
5/2-6/3-7/4-8, light blocks are separated into 4 groups with group #1 being light
blocks #1 & #5, group #2 being light blocks #2 & #6, group #3 being light blocks #3
& #7, and group #4 being light blocks #4 & #8.
:
TM SBTA84
18. Double Flash/Hyper
Single Alternating
Flash Combo 2 Group
1-2-3-4/5-6-7-8
19. Double Burst/Hyper
Single Alternating
Flash Combo 2 Group
1-2-3-4/5-6-7-8
