K Source Fit System 81850 Installation Instruction

Outside mirror removal and installation instructions.
Installation instruction
a. Disconnect the cable(s) from negative
battery terminal(s).
Remove the fasteners securing the inside
door handle.
b. Remove the inside door handle.
c. Pry out the armrest switch control plate
and disconnect the electrical connectors.
d. Remove the fasteners at the bottom of the
door panel.
Pull upward to release the door panel
hooks from the door.
e. Once all of the hooks are disengaged, raise
the trim panel up and off the door.
Disconnect any wiring harness connectors
and remove the trim panel from the
vehicle. On Models that have Manual
mirror's, skip to G.
f. Unplug the original mirror's electrical
connector.
g. Remove the nuts and detach the mirror
from the door.
h. Installation is reverse of removal.
FORD
F150 Pick-Up ..................................... 2004-2014
